EV2760 Swiss Edition
Model EV2760 Swiss EditionPart no. 22082
84 specifications Checked today
- Display68.6 cm (27")
- Resolution2560 x 1440 pixels
- ColourBlack
- NVIDIA G-SYNCNo
- Built-in speaker(s)Yes
- Market positioningBusiness
Overview
- Display
- 68.6 cm (27")
- Resolution
- 2560 x 1440 pixels
- Colour
- Black
- NVIDIA G-SYNC
- No
- Built-in speaker(s)
- Yes
- Market positioning
- Business
- Brand
- EIZO
- Category
- Monitor
- Model
- EV2760 Swiss Edition
- Part numbers
- 22082, 22083
- Also known as
- EIZO FlexScan EV2760 Swiss Edition computer monitor 68.6 cm (27") 2560 x 1440 pixels Quad HD LED Black
Specifications
84 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 2560 x 1440 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | Quad HD |
| Panel type | IPS |
| Display brightness (typical) | 350 cd/m² |
| Response time | 5 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 2560 x 1440 |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.233 x 0.233 mm |
| Pixel density | 109 ppi |
| Horizontal scan range | 31 - 89 kHz |
| Vertical scan range | 59 - 61 Hz |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| Colour gamut standard | sRGB |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Flicker-free technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 4 |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 2 |
| Audio input | Yes |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 16.9 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | -172 - 172° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 17 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Annual energy consumption | 25 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 611.7 mm |
| Depth (with stand) | 230 mm |
| Height (with stand) | 376.3 mm |
| Weight (with stand) | 8.5 kg |
| Width (without stand) | 611.7 mm |
| Depth (without stand) | 53.7 mm |
| Height (without stand) | 364.4 mm |
| Weight (without stand) | 5.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
| Cables included | AC, DisplayPort, USB |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, CB, TCO certified 8.0, EPA Energy Star, TÜV / GS, TÜV ergonomics tested (including ISO 9241-307), TÜV / Blue Low Light Content, TÜV / Flicker Free, EPEAT 2018 (US), cTÜVus, TÜV / S , EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, BSMI, BIS, CCC, RoHS, China RoHS, India RoHS, WEEE |
