FlexScan EV2456-BK computer monitor

61.2 cm (24.1") 1920 x 1200 pixels WUXGA LED Black

Model EV2456-BKEAN 4995047049722

89 specifications Checked yesterday

Overview

Brand: EIZO
Category: Monitor
Model: EV2456-BK
Part number: EV2456-BK
EAN / UPC: 4995047049722
Also known as: EIZO FlexScan EV2456-BK computer monitor 61.2 cm (24.1") 1920 x 1200 pixels WUXGA LED Black

89 specifications in 15 groups

Specification	Value
Display diagonal	61.2 cm (24.1")
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Display technology	LED
Touchscreen	No
HD type	WUXGA
Panel type	IPS
Display brightness (typical)	350 cd/m²
Response time	5 ms
Screen shape	Flat
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA)
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.78 million colours
Pixel pitch	0.27 x 0.27 mm
Horizontal scan range	31 - 81 kHz
Vertical scan range	55 - 76 Hz
Viewable size, horizontal	51.8 cm
Viewable size, vertical	32.4 cm
3D	No
Separate H/V sync	Yes

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Specification	Value
Product colour	Black

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	2
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDCP	Yes

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Height adjustment	Yes
Adjustable height (max)	15.9 cm
Pivot	Yes
Swivelling	Yes
Tilt adjustment	Yes
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Number of OSD languages	9
Plug and Play	Yes

Specification	Value
Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	14 kWh
Power consumption (typical)	13.5 W
Power consumption (standby)	0.5 W
Power consumption (max)	44 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Specification	Value
User Guide on CD-ROM	Yes

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Bronze, TCO
Sustainability compliance	Yes

Specification	Value
On/off switch	Yes
TV tuner integrated	No
Compliance certificates	CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE
No flickering	Yes
Power management	Yes
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Supplied AC adapter type	AC
