EV2430 Swiss Edition
Model EV2430 Swiss EditionPart no. 21868
80 specifications Checked today
- Display61.2 cm (24.1")
- Resolution1920 x 1200 pixels
- ColourBlack
- NVIDIA G-SYNCNo
- Built-in speaker(s)Yes
- Market positioningBusiness
Overview
- Display
- 61.2 cm (24.1")
- Resolution
- 1920 x 1200 pixels
- Colour
- Black
- NVIDIA G-SYNC
- No
- Built-in speaker(s)
- Yes
- Market positioning
- Business
- Brand
- EIZO
- Category
- Monitor
- Model
- EV2430 Swiss Edition
- Part number
- 21868
- Also known as
- EIZO FlexScan EV2430 Swiss Edition computer monitor 61.2 cm (24.1") 1920 x 1200 pixels WUXGA LED Black
Specifications
80 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 61.2 cm (24.1") |
| Display resolution | 1920 x 1200 pixels |
| Native aspect ratio | 16:10 |
| Display technology | LED |
| Touchscreen | No |
| HD type | WUXGA |
| Panel type | IPS |
| Backlight type | LED |
| Display brightness (typical) | 300 cd/m² |
| Response time | 14 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.27 x 0.27 mm |
| Viewable size, horizontal | 51.8 cm |
| Viewable size, vertical | 32.4 cm |
| Viewable size diagonal | 61.1 cm |
| Digital horizontal frequency | 31 - 76 kHz |
| Digital vertical frequency | 59 - 61 Hz |
| DDC/CI | Yes |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Flicker-free technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 2.0 |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI | No |
| DisplayPorts quantity | 1 |
| Audio input | Yes |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 14 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 12 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (off) | 0 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 552.5 mm |
| Depth (with stand) | 233 mm |
| Height (with stand) | 368 mm |
| Weight (with stand) | 6.7 kg |
| Width (without stand) | 552.5 mm |
| Depth (without stand) | 57 mm |
| Height (without stand) | 358 mm |
| Weight (without stand) | 4.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, DVI, DisplayPort |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | TCO Certified Generation 8, EPEAT (2018) (US), TÜV / Ergonomie, TÜV / GS, RCM, CE, CB, cTÜVus, FCC-B, ICES-003-B (CAN), TÜV / S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, EAC, BIS |
