EV2315W computer monitor

58.4 cm (23") 1920 x 1080 pixels Full HD LED Black

Model EV2315WPart no. EV2315W-BKEAN 690592032697

66 specifications Checked today

Overview

Brand: EIZO
Category: Monitor
Model: EV2315W
Part number: EV2315W-BK
EAN / UPC: 690592032697, 4995047039662
Also known as: EIZO EV2315W computer monitor 58.4 cm (23") 1920 x 1080 pixels Full HD LED Black

66 specifications in 10 groups

Specification	Value
Display diagonal	58.4 cm (23")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Full HD
Panel type	TN+Film
Display brightness (typical)	250 cd/m²
Response time	5 ms
Supported graphics resolutions	1920 x 1080 (HD 1080)
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.2655 x 0.2655 mm
Viewable size, horizontal	51 cm
Viewable size, vertical	28.7 cm
Viewable size diagonal	58.4 cm
Digital horizontal frequency	31 - 68 kHz
Digital vertical frequency	59 - 61 Hz
3D	No
Separate H/V sync	Yes

Specification	Value
Product colour	Black

Specification	Value
USB Type-A downstream ports quantity	0
VGA (D-Sub) ports quantity	1
DVI-D ports quantity	1
DVI-I ports quantity	0
HDMI ports quantity	0
Audio input	Yes
Audio output	Yes
Headphone connectivity	3.5 mm
HDCP	Yes
AC (power) in	Yes

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Pivot	Yes
Pivot angle	0 - 90°
Swivel angle range	-172 - 172°
Tilt angle range	0 - 30°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Number of OSD languages	9

Specification	Value
Power consumption (typical)	16 W
Power consumption (max)	31 W
Power consumption (PowerSave)	0.1 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%
