EIZO DuraVision FDF2306W

Model DuraVision FDF2306WPart no. FDF2306W-BKEAN 4995047047360

77 specifications Checked 4 days ago

Overview

Brand: EIZO
Category: Monitor
Model: DuraVision FDF2306W
Part number: FDF2306W-BK
EAN / UPC: 4995047047360
Also known as: EIZO DuraVision FDF2306W computer monitor 58.4 cm (23") 1920 x 1080 pixels Full HD LED Black

77 specifications in 12 groups

Specification	Value
Display diagonal	58.4 cm (23")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Full HD
Panel type	TN
Display brightness (typical)	250 cd/m²
Response time	10 ms
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.266 x 0.266 mm
Horizontal scan range	31 - 81 kHz
Vertical scan range	55 - 76 Hz
Viewable size, horizontal	51 cm
Viewable size, vertical	28.7 cm
Viewable size diagonal	58.4 cm
Digital horizontal frequency	15 - 68 kHz
Digital vertical frequency	49 - 61 Hz
3D	No
Separate H/V sync	Yes

Specification	Value
Product colour	Black

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Height adjustment	Yes
Adjustable height (max)	6 cm
Swivelling	Yes
Swivel angle range	0 - 344°
Tilt adjustment	Yes
Tilt angle range	0 - 25°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Number of OSD languages	9

Specification	Value
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	33 kWh
Power consumption (typical)	19 W
Power consumption (standby)	0.3 W
Power consumption (max)	38 W
Power consumption (PowerSave)	0.4 W
AC input voltage	100 - 240 V
Energy efficiency scale	A to G

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Specification	Value
User Guide on CD-ROM	Yes

Specification	Value
On/off switch	Yes
Certification	CB, CE, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, PSE, VCCI-B, CCC, RCM, EAC, RoHS, WEEE, China RoHS
Supplied AC adapter type	AC

Specification	Value
Harmonized System (HS) code	85285210
