ColorEdge CS2740-Photo computer monitor
68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LED Black
Model CS2740-PhotoPart no. 22085EAN 690592048650
73 specifications Checked today
- Display68.6 cm (27")
- Resolution3840 x 2160 pixels
- Energy classB
- ColourBlack
- Flicker-free technologyYes
- Market positioningGraphics design
Overview
- Display
- 68.6 cm (27")
- Resolution
- 3840 x 2160 pixels
- Energy class
- B
- Colour
- Black
- Flicker-free technology
- Yes
- Market positioning
- Graphics design
- Brand
- EIZO
- Category
- Monitor
- Model
- CS2740-Photo
- Part number
- 22085
- EAN / UPC
- 690592048650
- Also known as
- EIZO ColorEdge CS2740-Photo computer monitor 68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LED Black
Specifications
73 specifications in 10 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 3840 x 2160 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | IPS |
| Backlight type | LED |
| Display brightness (typical) | 350 cd/m² |
| Response time | 10 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160 |
| Supported video modes | 480i, 576p, 720p, 1080i, 1080p |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.155 x 0.155 mm |
| Pixel density | 164 ppi |
| Viewable size, horizontal | 59.6 cm |
| Viewable size, vertical | 33.5 cm |
| Digital horizontal frequency | 15 - 135 kHz |
| Digital vertical frequency | 23 - 61 Hz |
Performance
| Specification | Value |
|---|---|
| Flicker-free technology | Yes |
Design
| Specification | Value |
|---|---|
| Market positioning | Graphics design |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports | 2 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery up to | 60 W |
| DVI port | No |
| HDMI | Yes |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.3 |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | Yes |
| Adjustable height (max) | 15.5 cm |
| Pivot | Yes |
| Pivot angle | 0 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 344° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 35° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 8 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 36 W |
| Power consumption (standby) | 1 W |
| Power consumption (off) | 0 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Annual energy consumption | 62 kWh |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 638 mm |
| Depth (with stand) | 265 mm |
| Height (with stand) | 559 mm |
| Weight (with stand) | 10.3 kg |
| Width (without stand) | 638 mm |
| Depth (without stand) | 75 mm |
| Height (without stand) | 378.2 mm |
| Weight (without stand) | 6.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
| Cables included | AC, DisplayPort, USB Type-C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Energy efficiency class (legacy scale) | B |
| Certification | CB, CE, TÜV / GS, TÜV / Ergonomie, TÜV / Color Accuracy (Quick Stability), FograCert Softproofing System (class A, cTÜVus, TÜV / S, EAC, PSE, FCC-B, ICES-003-B (CAN) , RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE |
