ColorEdge CS2420 computer monitor

61.2 cm (24.1") 1920 x 1200 pixels WUXGA LED Black

Model CS2420Part no. 21662EAN 4995047048091

85 specifications Checked today

Overview

Brand: EIZO
Category: Monitor
Model: CS2420
Part numbers: 21662, CS2420CAL, CS2420-BK + SPYDER5, CS2420-EX4, CS2420
EAN / UPC: 4995047048091, 4995047049609
Also known as: EIZO ColorEdge CS2420 computer monitor 61.2 cm (24.1") 1920 x 1200 pixels WUXGA LED Black

85 specifications in 13 groups

Specification	Value
Display diagonal	61.2 cm (24.1")
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Display technology	LED
Touchscreen	No
HD type	WUXGA
Panel type	IPS
Display brightness (typical)	350 cd/m²
Display brightness (min)	120 cd/m²
Response time	15 ms
Display surface	Matt
Screen shape	Flat
Supported graphics resolutions	1920 x 1200 (WUXGA)
Aspect ratio	16:10
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.78 million colours
Pixel pitch	0.2701 x 0.2701 mm
Pixel density	94 ppi
Viewable size, horizontal	51.8 cm
Viewable size, vertical	32.4 cm
Colour gamut standard	sRGB
Colour gamut	99%

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Specification	Value
Market positioning	Graphics design
Product colour	Black

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	4
VGA (D-Sub) ports quantity	0
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	1
HDCP	Yes
AC (power) in	Yes

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Height adjustment	Yes
Adjustable height (max)	15.5 cm
Pivot	Yes
Pivot angle	0 - 90°
Swivelling	Yes
Swivel angle range	-344 - 344°
Tilt adjustment	Yes
Tilt angle range	-5 - 35°
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Number of OSD languages	9
LED indicators	Yes

Specification	Value
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	28.2 kWh
Power consumption (typical)	28.2 W
Power consumption (standby)	0.5 W
Power consumption (max)	92 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Specification	Value
Stand included	Yes
Cables included	AC, DVI, DisplayPort, Mini DisplayPort, USB
Quick start guide	Yes
Manual	Yes

Specification	Value
On/off switch	Yes
TV tuner integrated	No
Power management	Yes
Certification	CB, CE, TUV/GS, cTUVus, FCC-B, Canadian ICES-003-B, VCCI-B, TUV/Ergonomics, RCM, RoHS, WEEE, EAC
Supplied AC adapter type	AC
