EIZO 18IN 28MM 1280X1024 80KHZ

EIZO 18IN 28MM 1280X1024 80KHZ

Model 18IN 28MM 1280X1024 80KHZPart no. L685

21 specifications Checked 7 days ago

Display46 cm (18.1")
Resolution1280 x 1024 pixels
Plug and PlayYes
Power consumption (typical)56 W

See all specifications

Overview

Display: 46 cm (18.1")
Resolution: 1280 x 1024 pixels
Plug and Play: Yes
Power consumption (typical): 56 W

Brand: EIZO
Category: Monitor
Model: 18IN 28MM 1280X1024 80KHZ
Part numbers: L685, L685EX, L685EXK
Also known as: EIZO 18IN 28MM 1280X1024 80KHZ computer monitor 46 cm (18.1") 1280 x 1024 pixels

Specifications

21 specifications in 7 groups

Display

Specification	Value
Display diagonal	46 cm (18.1")
Display resolution	1280 x 1024 pixels
Touchscreen	No
Display brightness (typical)	250 cd/m²
Response time	40 ms
Contrast ratio (typical)	400:1
Viewing angle, horizontal	170°
Viewing angle, vertical	170°
Pixel pitch	0.2805
Horizontal scan range	27 - 82 kHz
Vertical scan range	50 - 85 Hz
Viewable size, horizontal	35.9 cm
Viewable size, vertical	28.7 cm

Ports & interfaces

Specification	Value
I/O ports	2 x DVI-I 29 pin, USB 1.1: 1x upstream, 4 x downstream

Ergonomics

Specification	Value
Plug and Play	Yes

Power

Specification	Value
Power consumption (typical)	56 W

Packaging content

Specification	Value
Bundled software	Drivers & Utilities

Other features

Specification	Value
Audio system	No
Power requirements	110-120/220-240V, 50.60Hz
Certification	TCO‘99, TUV/Ergonomics, TUV/GS, c-Tick, CE, CB, UL 1950, CSA C22.2 No.950, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA ENERGY STAR

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
