Dell UltraSharp 32 4K USB-C Hub Monitor - U3223QE
Dell

UltraSharp 32 4K USB-C Hub Monitor - U3223QE

Model U3223QEEAN 5715063338063

128 specifications Checked today
  • Display80 cm (31.5")
  • Resolution3840 x 2160 pixels
  • Energy classF
  • ColourSilver
  • NVIDIA G-SYNCNo
  • Market positioningGraphics design
See all specifications

Overview

Display
80 cm (31.5")
Resolution
3840 x 2160 pixels
Energy class
F
Colour
Silver
NVIDIA G-SYNC
No
Market positioning
Graphics design
Brand
Dell
Category
Monitor
Model
U3223QE
Part numbers
U3223QE, DELL-U3223QE
EAN / UPC
5715063338063, 884116414209, 5397184567739, 5715063338070
Also known as
DELL UltraSharp 32 4K USB-C Hub Monitor - U3223QE

Specifications

128 specifications in 16 groups

Display

Display diagonal80 cm (31.5")
Display resolution3840 x 2160 pixels
Native aspect ratio16:9
Display technologyLCD
TouchscreenNo
HD type4K Ultra HD
Panel typeIPS Black
Backlight typeLED
Display brightness (typical)400 cd/m²
Response time8 ms
Anti-glare screenYes
Screen shapeFlat
Supported video modes1080i, 1080p, 480p, 720p, 576p
Contrast ratio (typical)2000:1
Maximum refresh rate60 Hz
Viewing angle, horizontal178°
Viewing angle, vertical178°
Display number of colours1.07 billion colours
Response time (fast)5 ms
Pixel pitch0.18159 x 0.18159 mm
Pixel density137.68 ppi
Horizontal scan range15 - 140 kHz
Vertical scan range23 - 86 Hz
Viewable size, horizontal69.7 cm
Viewable size, vertical39.2 cm
Display diagonal (metric)80.01 cm
High Dynamic Range (HDR) supportedNo
DDC/CIYes
Surface hardness3H
Colour gamut standardsRGB
sRGB coverage (typical)100%
DCI-P3 coverage98%
Heat dissipation98.27 BTU/h

Performance

NVIDIA G-SYNCNo
AMD FreeSyncNo
Flicker-free technologyYes
Low Blue Light technologyYes

Multimedia

Built-in speaker(s)No
Number of speakers0
RMS rated power0 W
Built-in cameraNo

Design

Market positioningGraphics design
Product colourSilver
Front bezel colourBlack
Feet colourSilver

Ports & interfaces

Built-in USB hubYes
USB hub version3.2 Gen 2 (3.1 Gen 2)
USB upstream port typeUSB Type-C
Number of upstream ports2
Number of USB Type-C upstream ports quantity1
USB Type-A downstream ports quantity5
USB Type-C downstream ports quantity0
USB Power Delivery (USB PD)Yes
USB Power Delivery up to90 W
VGA (D-Sub) ports quantity0
HDMIYes
HDMI ports quantity1
HDMI version2.0
DisplayPorts quantity2
Audio outputYes
Headphone outYes
Headphone outputs1
Headphone connectivity3.5 mm
HDCPYes

Network

Wi-FiNo

Ergonomics

VESA mountingYes
Panel mounting interface100 x 100 mm
Cable lock slotYes
Height adjustmentYes
PivotNo
SwivellingYes
Swivel angle range-30 - 30°
Tilt adjustmentYes
Tilt angle range-5 - 21°
On Screen Display (OSD)Yes
Plug and PlayYes

Power

Energy efficiency class (SDR)F
Energy efficiency class (HDR)E
Energy consumption (SDR) per 1000 hours29 kWh
Energy consumption (HDR) per 1000 hours26 kWh
Power consumption (typical)29.4 W
Power consumption (standby)0.3 W
Power consumption (max)220 W
Power consumption (off)0.2 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current2.7 A
Power supply typeInternal
Energy efficiency scaleA to G

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)10 - 80%
Storage relative humidity (H-H)5 - 90%
Operating altitude0 - 5000 m
Non-operating altitude0 - 12192 m

Weight & dimensions

Width (with stand)712.6 mm
Depth (with stand)233.2 mm
Height (with stand)469.3 mm
Weight (with stand)9.98 kg
Width (without stand)712.6 mm
Depth (without stand)55.8 mm
Height (without stand)410 mm
Weight (without stand)5.65 kg
Bezel width (side)7.65 mm
Bezel width (top)7.65 mm
Bezel width (bottom)1.01 cm

Packaging data

Package weight14.5 kg

Packaging content

Stand includedYes
Cables includedAC, DisplayPort, USB Type-C to USB Type-A, USB Type-C to USB Type-C
Quick start guideYes

Sustainability

Sustainability certificatesTCO, ENERGY STAR, EPEAT Gold
Doesn't containPVC/BFR, Arsenic

Carbon footprint

Carbon emissions, end-of-life (kg of CO2e)7.92
Carbon emissions, energy usage (kg of CO2e)320.32
Carbon emissions, logistics (kg of CO2e)119.68
Carbon emissions, manufacturing (kg of CO2e)432.08
PAIA versionPAIA 1.3.0, 2021
Total carbon emissions, standard deviation (kg of CO2e)210
Total carbon footprint (kg of CO2e)880

Other features

Picture-by-Picture (PbP)Yes
Compliance certificatesRoHS
Heavy metals freeHg (mercury)
RJ-45 ports quantity1
Ethernet LAN (RJ-45) ports0
Power managementYes
Compliance industry standardsENERGY STAR certified Monitor. EPEAT registered where applicable. TCO Certified & TCO Certified Edge. RoHS Compliant. BFR/PVC Free monitor Meets NFPA 99 leakage current requirements. Arsenic-Free glass and Mercury-Free for the panel only.
Supplied AC adapter type3840 x 2160

Logistics data

Harmonized System (HS) code85285210

Energy efficiency

ENERGY STAR certified

Displays · model U3223QET · certified Jul 9, 2021 · United States, Switzerland, Taiwan, Japan, Canada

On-mode power29.61 W
Sleep-mode power0.5 W
Off-mode power0.21 W
