UltraSharp 30 USB-C Hub Monitor - U3023E

Model U3023EPart no. DELL-U3023EEAN 884116398868

129 specifications Checked today

Display76.2 cm (30")
Resolution2560 x 1600 pixels
Energy classF
ColourSilver
NVIDIA G-SYNCNo
Market positioningGraphics design

See all specifications

Overview

Display: 76.2 cm (30")
Resolution: 2560 x 1600 pixels
Energy class: F
Colour: Silver
NVIDIA G-SYNC: No
Market positioning: Graphics design

Brand: Dell
Category: Monitor
Model: U3023E
Part number: DELL-U3023E
EAN / UPC: 884116398868, 5397184567593, 5715063472811
Also known as: DELL UltraSharp 30 USB-C Hub Monitor - U3023E

Specifications

129 specifications in 16 groups

Display

Specification	Value
Display diagonal	76.2 cm (30")
Display resolution	2560 x 1600 pixels
Native aspect ratio	16:10
Display technology	LCD
Touchscreen	No
HD type	WQXGA
Panel type	IPS
Backlight type	LED
Display brightness (typical)	350 cd/m²
Response time	8 ms
Anti-glare screen	Yes
Screen shape	Flat
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Response time (fast)	5 ms
Pixel pitch	0.2505 x 0.2505 mm
Pixel density	101.4 ppi
Horizontal scan range	30 - 113 kHz
Vertical scan range	56 - 76 Hz
Viewable size, horizontal	64.1 cm
Viewable size, vertical	40.1 cm
Display diagonal (metric)	75.62 cm
High Dynamic Range (HDR) supported	No
DDC/CI	Yes
Surface hardness	3H
Colour gamut standard	sRGB
sRGB coverage (typical)	100%
DCI-P3 coverage	95%
Heat dissipation (typical)	90.76 BTU/h

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Graphics design
Product colour	Silver
Front bezel colour	Black
Feet colour	Silver

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 2 (3.1 Gen 2)
USB upstream port type	USB Type-C
Number of upstream ports	2
Number of USB Type-C upstream ports quantity	0
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	2
Audio output	Yes
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDCP	Yes
Charging port type	USB Type-C + USB Type-A
AC (power) in	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	15 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	-30 - 30°
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	27 kWh
Power consumption (typical)	26.6 W
Power consumption (standby)	0.3 W
Power consumption (max)	210 W
Power consumption (off)	0.2 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	655.9 mm
Depth (with stand)	230 mm
Height (with stand)	472.7 mm
Weight (with stand)	10.8 kg
Width (without stand)	655.9 mm
Depth (without stand)	53 mm
Height (without stand)	418.6 mm
Weight (without stand)	6.48 kg
Bezel width (side)	7.3 mm
Bezel width (top)	7.3 mm
Bezel width (bottom)	1.05 cm

Packaging data

Specification	Value
Package weight	15.1 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort, USB Type-C, USB Type-C to USB Type-A
Quick start guide	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Gold
Doesn't contain	Arsenic, PVC/BFR

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	8.59
Carbon emissions, energy usage (kg of CO2e)	255
Carbon emissions, logistics (kg of CO2e)	137
Carbon emissions, manufacturing (kg of CO2e)	418.5
PAIA version	1.3.0, 2021
Total carbon emissions, standard deviation (kg of CO2e)	177
Total carbon footprint (kg of CO2e)	820

Other features

Specification	Value
On/off switch	Yes
Picture-by-Picture (PbP)	Yes
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
RJ-45 ports quantity	1
Ethernet LAN (RJ-45) ports	0
Power management	Yes
Compliance industry standards	ENERGY STAR certified Monitor. EPEAT registered where applicable. TCO Certified & TCO Certified Edge. RoHS Compliant. BFR/PVC Free monitor Meets NFPA 99 leakage current requirements. Arsenic-Free glass and Mercury-Free for the panel only.
Supplied AC adapter type	2560 x 1600

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
