S Series S3422DW computer monitor

86.4 cm (34") 3440 x 1440 pixels Wide Quad HD LCD Silver

Model S3422DWEAN 5704174536376

113 specifications Checked today

Display86.4 cm (34")
Resolution3440 x 1440 pixels
Energy classG
ColourSilver
NVIDIA G-SYNCNo
Built-in speaker(s)Yes

See all specifications

Overview

Display: 86.4 cm (34")
Resolution: 3440 x 1440 pixels
Energy class: G
Colour: Silver
NVIDIA G-SYNC: No
Built-in speaker(s): Yes

Brand: Dell
Category: Monitor
Model: S3422DW
Part numbers: S3422DW, B08YDQTN4Z-DT-ROW, DELL-S3422DW
EAN / UPC: 5704174536376, 884116375630, 5397184409459, 5397184657034
Also known as: DELL S Series S3422DW computer monitor 86.4 cm (34") 3440 x 1440 pixels Wide Quad HD LCD Silver

Specifications

113 specifications in 16 groups

Display

Specification	Value
Display diagonal	86.4 cm (34")
Display resolution	3440 x 1440 pixels
Native aspect ratio	21:9
Display technology	LCD
Touchscreen	No
HD type	Wide Quad HD
Panel type	VA
Display brightness (typical)	300 cd/m²
Response time	4 ms
Anti-glare screen	Yes
Screen shape	Curved
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Contrast ratio (typical)	3000:1
Maximum refresh rate	100 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Horizontal scan range	30 - 160 kHz
Vertical scan range	48 - 100 Hz
Viewable size, horizontal	79.7 cm
Viewable size, vertical	33.4 cm
Viewable size diagonal	86.4 cm
Display diagonal (metric)	86.42 cm
High Dynamic Range (HDR) supported	No
Colour gamut standard	DCI-P3
Colour gamut	89.2%
sRGB coverage (typical)	99%
DCI-P3 coverage	90%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	Yes
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	10 W
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Silver
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Silver

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	2
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	2
HDMI version	2.2
DisplayPorts quantity	1
DisplayPort version	1.2
Audio output	Yes
HDCP	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	10 cm
Pivot	No
Swivelling	No
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	32 kWh
Power consumption (typical)	32 W
Power consumption (standby)	0.3 W
Power consumption (max)	92 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
Power supply type	Internal

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	808.2 mm
Depth (with stand)	210 mm
Height (with stand)	489.4 mm
Weight (with stand)	9.8 kg
Width (without stand)	808.2 mm
Depth (without stand)	64 mm
Height (without stand)	364.5 mm
Weight (without stand)	6.7 kg
Bezel width (side)	8.65 mm
Bezel width (top)	8.64 mm
Bezel width (bottom)	2.21 cm

Packaging data

Specification	Value
Package width	468.1 mm
Package depth	950 mm
Package height	225 mm
Package weight	14.9 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, HDMI, USB
Quick start guide	Yes

Sustainability

Specification	Value
Doesn't contain	PVC/BFR

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	8
Carbon emissions, energy usage (kg of CO2e)	359
Carbon emissions, logistics (kg of CO2e)	72
Carbon emissions, manufacturing (kg of CO2e)	382
PAIA version	1.3.2
Total carbon emissions, standard deviation (kg of CO2e)	264
Total carbon emissions, w/o use phase (kg of CO2e)	462
Total carbon footprint (kg of CO2e)	821

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
