S Series S3222DGM computer monitor

80 cm (31.5") 2560 x 1440 pixels Wide Quad HD LCD Black

Model S3222DGMPart no. DELL-S3222DGMEAN 884116395911

101 specifications Checked today

Display80 cm (31.5")
Resolution2560 x 1440 pixels
Energy classE
ColourBlack
AMD FreeSyncYes
Built-in speaker(s)No

See all specifications

Overview

Display: 80 cm (31.5")
Resolution: 2560 x 1440 pixels
Energy class: E
Colour: Black
AMD FreeSync: Yes
Built-in speaker(s): No

Brand: Dell
Category: Monitor
Model: S3222DGM
Part numbers: DELL-S3222DGM, S3222DGM
EAN / UPC: 884116395911, 5397184505120, 5715063782750
Also known as: DELL S Series S3222DGM computer monitor 80 cm (31.5") 2560 x 1440 pixels Wide Quad HD LCD Black

Specifications

101 specifications in 15 groups

Display

Specification	Value
Display diagonal	80 cm (31.5")
Display resolution	2560 x 1440 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Wide Quad HD
Panel type	VA
Backlight type	LED
Display brightness (typical)	350 cd/m²
Response time	1 ms
Screen shape	Curved
Screen curvature rating	1800R
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080p, 1440p
Contrast ratio (typical)	3000:1
Maximum refresh rate	165 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Response time (fast)	8 ms
Pixel pitch	0.2724 x 0.2724 mm
Pixel density	93 ppi
Horizontal scan range	30 - 250 kHz
Vertical scan range	48 - 165 Hz
Viewable size, horizontal	69.7 cm
Viewable size, vertical	39.2 cm
Viewable size diagonal	80 cm
Display diagonal (metric)	80.01 cm
High Dynamic Range (HDR) supported	No
Colour depth	8 bit
sRGB coverage (typical)	99%

Performance

Specification	Value
AMD FreeSync	Yes
AMD FreeSync type	FreeSync Premium

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Gaming
Product colour	Black
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Black

Ports & interfaces

Specification	Value
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	2
HDMI version	2.0
DisplayPorts quantity	1
DisplayPort version	1.2
Headphone out	Yes
Headphone outputs	1

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	10 cm
Pivot	No
Swivelling	No
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	26 kWh
Power consumption (typical)	26 W
Power consumption (standby)	0.3 W
Power consumption (max)	50 W
Power consumption (off)	0.25 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	708.8 mm
Depth (with stand)	237.6 mm
Height (with stand)	556 mm
Weight (with stand)	9.71 kg
Width (without stand)	708.8 mm
Depth (without stand)	82.4 mm
Height (without stand)	424.2 mm
Weight (without stand)	7.44 kg
Bezel width (side)	7.92 mm
Bezel width (top)	7.85 mm
Bezel width (bottom)	2.41 cm

Packaging data

Specification	Value
Package width	525 mm
Package depth	939.8 mm
Package height	199.9 mm
Package weight	14.5 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort, HDMI
Quick start guide	Yes
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m

Sustainability

Specification	Value
Doesn't contain	PVC/BFR

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
