P Series 24 USB-C Hub Monitor - P2423DE

Model P2423DEEAN 5704174839576

120 specifications Checked today

Display60.5 cm (23.8")
Resolution2560 x 1440 pixels
Energy classF
ColourBlack
NVIDIA G-SYNCNo
Market positioningBusiness

See all specifications

Overview

Display: 60.5 cm (23.8")
Resolution: 2560 x 1440 pixels
Energy class: F
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Business

Brand: Dell
Category: Monitor
Model: P2423DE
Part numbers: P2423DE, DELL-P2423DE
EAN / UPC: 5704174839576, 884116417897, 5397184567975, 5704174839545 +1 more
Also known as: DELL P Series 24 USB-C Hub Monitor - P2423DE

Specifications

120 specifications in 16 groups

Display

Specification	Value
Display diagonal	60.5 cm (23.8")
Display resolution	2560 x 1440 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Quad HD
Panel type	IPS
LED backlight	Yes
Backlight type	Edge LED
Display brightness (typical)	300 cd/m²
Response time	5 ms
Anti-glare screen	Yes
Screen shape	Flat
Supported video modes	480p, 576p, 720p, 1080i, 1080p, 1440p
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Response time (fast)	8 ms
Pixel pitch	0.2058 x 0.2058 mm
Pixel density	123 ppi
Horizontal scan range	29 - 113 kHz
Vertical scan range	49 - 75 Hz
Viewable size, horizontal	52.7 cm
Viewable size, vertical	29.6 cm
Viewable size diagonal	60.5 cm
Display diagonal (metric)	60.45 cm
High Dynamic Range (HDR) supported	No
sRGB coverage (typical)	99%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Black
Frameless design	Yes
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Silver

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB upstream port type	USB Type-C
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	0
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	2
DisplayPort version	1.4
Headphone out	No
HDCP	Yes
Charging port type	USB Type-C
AC (power) in	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	15 cm
Pivot	Yes
Pivot angle	90 - 90°
Swivelling	Yes
Swivel angle range	-45 - 45°
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes
LED indicators	Yes

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	20 kWh
Power consumption (typical)	20 W
Power consumption (standby)	0.3 W
Power consumption (max)	170 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	2 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	537.8 mm
Depth (with stand)	179.6 mm
Height (with stand)	496.1 mm
Weight (with stand)	5.55 kg
Width (without stand)	537.8 mm
Depth (without stand)	52.1 mm
Height (without stand)	318.5 mm
Weight (without stand)	3.92 kg
Bezel width (side)	5.48 mm
Bezel width (top)	5.42 mm
Bezel width (bottom)	1.67 cm

Packaging data

Specification	Value
Package weight	7.97 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort, USB Type-A to USB Type-C, USB Type-C to USB Type-C
Quick start guide	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, TCO
Doesn't contain	PVC/BFR, Arsenic, Mercury

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	4.11
Carbon emissions, energy usage (kg of CO2e)	191.36
Carbon emissions, logistics (kg of CO2e)	69.85
Carbon emissions, manufacturing (kg of CO2e)	321.68
PAIA version	PAIA 1.3.0, 2021
Total carbon emissions, standard deviation (kg of CO2e)	140
Total carbon footprint (kg of CO2e)	587

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	1

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
