Dell P2317H computer monitor

58.4 cm (23") 1920 x 1080 pixels Full HD LCD Black

Model P2317HPart no. 9KFDWEAN 5706998583321

117 specifications Checked 3 days ago

Display58.4 cm (23")
Resolution1920 x 1080 pixels
Energy classA+
ColourBlack
NVIDIA G-SYNCNo
Market positioningBusiness

See all specifications

Overview

Display: 58.4 cm (23")
Resolution: 1920 x 1080 pixels
Energy class: A+
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Business

Brand: Dell
Category: Monitor
Model: P2317H
Part numbers: 9KFDW, 210-AJEM, P2317H, P2317HWH-WHITE, 210-AIIB, 2WDRP +1 more
EAN / UPC: 5706998583321, 4058154092163, 4058154127483, 5397063744596 +6 more
Also known as: DELL P2317H computer monitor 58.4 cm (23") 1920 x 1080 pixels Full HD LCD Black

Specifications

117 specifications in 17 groups

Display

Specification	Value
Display diagonal	58.4 cm (23")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	IPS
Backlight type	LED
Display brightness (typical)	250 cd/m²
Response time	6 ms
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	4000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.78 million colours
Pixel pitch	0.265 x 0.265 mm
Pixel density	96 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	56 - 76 Hz
Viewable size, horizontal	50.9 cm
Viewable size, vertical	28.6 cm
NTSC coverage (typical)	82%
3D	No

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	4
VGA (D-Sub) ports quantity	1
DVI port	No
HDMI	Yes
HDMI ports quantity	1
DisplayPorts quantity	1
AC (power) in	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	13 cm
Pivot	Yes
Pivot angle	0 - 90°
Swivelling	Yes
Swivel angle range	-45 - 45°
Tilt adjustment	Yes
Tilt angle range	-5 - 21°

Power

Specification	Value
Power consumption (typical)	18 W
Power consumption (standby)	0.3 W
Power consumption (max)	38 W
Power consumption (off)	0.3 W
Power consumption (PowerSave)	14.8 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	1.5 A
Annual energy consumption	22 kWh

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m

Weight & dimensions

Specification	Value
Width (with stand)	532 mm
Depth (with stand)	180 mm
Height (with stand)	487.1 mm
Weight (with stand)	5.16 kg
Width (without stand)	532 mm
Depth (without stand)	50.3 mm
Height (without stand)	315.9 mm
Weight (without stand)	3.06 kg
Bezel width (side)	1.14 cm
Bezel width (top)	1.14 cm
Bezel width (bottom)	1.81 cm

Packaging data

Specification	Value
Package width	167.9 mm
Package depth	606 mm
Package height	380 mm
Package weight	7.32 kg
Package material	Corrugated cardboard, Paper molded pulp, Polyethylene (PE)

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort, USB, VGA
Quick start guide	Yes

Sustainability

Specification	Value
Sustainability certificates	TCO, EPEAT Gold, ENERGY STAR

Other features

Specification	Value
On/off switch	Yes
TV tuner integrated	No
Compliance certificates	RoHS
Energy efficiency class (legacy scale)	A+
Certification	CECP, CEL
Supplied AC adapter type	LED

Recycling data

Specification	Value
Corrugated cardboard content per package	1.19 kg
Paper molded pulp content per package	450 g
Polyethylene (PE) content per bag	54.55 g

Brand-specific features

Specification	Value
Dell Display Manager (DDM) compatibility	Yes

Thin Client

Specification	Value
Thin client installed	No

Logistics data

Specification	Value
Products per master (outer) case	1 pc(s)
Master (outer) case width	167.9 mm
Master (outer) case length	606 mm
Master (outer) case height	380 mm
Master (outer) case gross weight	7.34 kg
Master (outer) cases per pallet	24 pc(s)
Products per pallet	24 pc(s)
Products per pallet layer	12 pc(s)
Layers per pallet	2 pc(s)
Pallet gross width	101.6 cm
Pallet gross length	121.9 cm
Pallet gross height	88 cm
Pallet gross weight	196.2 kg
