P Series 22 Inch USB-C Hub Monitor - P2223HC

Model P2223HCPart no. DELL-P2223HCEAN 884116417859

118 specifications Checked today

Display54.6 cm (21.5")
Resolution1920 x 1080 pixels
Energy classD
ColourBlack
NVIDIA G-SYNCNo
Market positioningBusiness

See all specifications

Overview

Display: 54.6 cm (21.5")
Resolution: 1920 x 1080 pixels
Energy class: D
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Business

Brand: Dell
Category: Monitor
Model: P2223HC
Part number: DELL-P2223HC
EAN / UPC: 884116417859, 5397184567944, 5715063019313
Also known as: DELL P Series 22 Inch USB-C Hub Monitor - P2223HC

Specifications

118 specifications in 16 groups

Display

Specification	Value
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	IPS
Backlight type	LED
Display brightness (typical)	250 cd/m²
Response time	14 ms
Anti-glare screen	Yes
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Response time (fast)	5 ms
Pixel pitch	0.24795 x 0.24795 mm
Pixel density	102.46 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	56 - 76 Hz
Viewable size, horizontal	47.6 cm
Viewable size, vertical	26.8 cm
Viewable size diagonal	54.6 cm
Display diagonal (metric)	54.61 cm
High Dynamic Range (HDR) supported	No
Surface hardness	3H
Colour gamut standard	sRGB
sRGB coverage (typical)	99%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Black
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Silver

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	0
USB Power Delivery up to	65 W
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	2
Headphone out	No
HDCP	Yes
AC (power) in	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	15 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	-45 - 45°
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
LED indicators	Power

Power

Specification	Value
Energy efficiency class (SDR)	D
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	12 kWh
Power consumption (typical)	12 W
Power consumption (standby)	0.3 W
Power consumption (max)	118 W
Power consumption (off)	0.2 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	1.5 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	487.3 mm
Depth (with stand)	179.6 mm
Height (with stand)	364 mm
Weight (with stand)	4.97 kg
Width (without stand)	487.3 mm
Depth (without stand)	52.1 mm
Height (without stand)	290 mm
Weight (without stand)	3.36 kg
Bezel width (side)	5.6 mm
Bezel width (top)	5.6 mm
Bezel width (bottom)	1.66 cm

Packaging data

Specification	Value
Package weight	6.63 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort, USB Type-C
Quick start guide	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
Doesn't contain	PVC/BFR

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	3.81
Carbon emissions, energy usage (kg of CO2e)	130.56
Carbon emissions, logistics (kg of CO2e)	58.75
Carbon emissions, manufacturing (kg of CO2e)	350.88
PAIA version	PAIA 1.3.0, 2021
Total carbon emissions, standard deviation (kg of CO2e)	117
Total carbon footprint (kg of CO2e)	544

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0
Power management	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
