E Series 24 Monitor – E2422HS

Model E2422HSPart no. DELL-E2422HSEAN 884116404118

105 specifications Checked today

Display60.5 cm (23.8")
Resolution1920 x 1080 pixels
Energy classE
ColourBlack
Flicker-free technologyYes
Market positioningBusiness

See all specifications

Overview

Display: 60.5 cm (23.8")
Resolution: 1920 x 1080 pixels
Energy class: E
Colour: Black
Flicker-free technology: Yes
Market positioning: Business

Brand: Dell
Category: Monitor
Model: E2422HS
Part numbers: DELL-E2422HS, E2422HS
EAN / UPC: 884116404118, 5397184567685
Also known as: DELL E Series 24 Monitor – E2422HS

Specifications

105 specifications in 16 groups

Display

Specification	Value
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	IPS
LED backlight	Yes
Backlight type	Edge LED
Display brightness (typical)	250 cd/m²
Response time	8 ms
Anti-glare screen	Yes
Screen shape	Flat
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080)
Supported video modes	1080p
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Response time (fast)	5 ms
Pixel pitch	0.2745 x 0.2745 mm
Pixel density	93 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	50 - 75 Hz
Viewable size, horizontal	52.7 cm
Viewable size, vertical	29.6 cm
Viewable size diagonal	60.5 cm
Sync-on-green (SOG)	Yes
Display diagonal (metric)	60.5 cm
High Dynamic Range (HDR) supported	No
Surface hardness	3H
Colour gamut	72%

Performance

Specification	Value
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	1 W
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Black
Front bezel colour	Black
Feet colour	Black

Ports & interfaces

Specification	Value
VGA (D-Sub) ports quantity	1
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DisplayPort version	1.2
Headphone out	No

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	10 cm
Pivot	No
Swivelling	No
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	16 kWh
Power consumption (typical)	16 W
Power consumption (standby)	0.3 W
Power consumption (max)	28 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	1.5 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	552.6 mm
Depth (with stand)	187.3 mm
Height (with stand)	490.3 mm
Weight (with stand)	4.88 kg
Width (without stand)	552.6 mm
Depth (without stand)	49.7 mm
Height (without stand)	331.6 mm
Weight (without stand)	3.24 kg
Bezel width (side)	1.28 cm
Bezel width (top)	1.28 cm
Bezel width (bottom)	2.23 cm

Packaging data

Specification	Value
Package weight	6.4 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, HDMI

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Gold

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	1.48
Carbon emissions, energy usage (kg of CO2e)	140.79
Carbon emissions, logistics (kg of CO2e)	30.63
Carbon emissions, manufacturing (kg of CO2e)	321.1
PAIA version	PAIA 1.2.15, 2021
Total carbon emissions, standard deviation (kg of CO2e)	95
Total carbon footprint (kg of CO2e)	494

Other features

Specification	Value
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
