E Series 22 Inch Monitor - E2223HN

Model E2223HNEAN 5715328090941

108 specifications Checked today

Display54.5 cm (21.4")
Resolution1920 x 1080 pixels
Energy classD
ColourBlack
NVIDIA G-SYNCNo
Market positioningOffice

See all specifications

Overview

Display: 54.5 cm (21.4")
Resolution: 1920 x 1080 pixels
Energy class: D
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Office

Brand: Dell
Category: Monitor
Model: E2223HN
Part numbers: E2223HN, DELL-E2223HN
EAN / UPC: 5715328090941, 884116398813, 5397184505359, 5715063783122
Also known as: DELL E Series 22 Inch Monitor - E2223HN

Specifications

108 specifications in 15 groups

Display

Specification	Value
Display diagonal	54.5 cm (21.4")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	VA
Backlight type	LED
Display brightness (typical)	250 cd/m²
Response time	10 ms
Anti-glare screen	Yes
Screen shape	Flat
Contrast ratio (typical)	3000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Response time (fast)	5 ms
Pixel pitch	0.249 x 0.241 mm
Pixel density	103 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	50 - 75 Hz
Viewable size, horizontal	47.9 cm
Viewable size, vertical	26 cm
Viewable size diagonal	54.5 cm
Display diagonal (metric)	54.48 cm
High Dynamic Range (HDR) supported	No
Colour gamut standard	DCI-P3
Colour gamut	83%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Multimedia

Specification	Value
Built-in speaker(s)	No
Number of speakers	0
RMS rated power	0 W
Built-in camera	No

Design

Specification	Value
Market positioning	Office
Product colour	Black
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
Number of USB Type-C upstream ports quantity	0
USB Type-C downstream ports quantity	0
VGA (D-Sub) ports quantity	1
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	0
Headphone out	No
AC (power) in	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	No
Pivot	No
Swivelling	No
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes
LED indicators	Yes

Power

Specification	Value
Energy efficiency class (SDR)	D
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	12 kWh
Power consumption (typical)	12.83 W
Power consumption (standby)	0.3 W
Power consumption (max)	19 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	0.7 A
Power supply type	Internal

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	504.3 mm
Depth (with stand)	171 mm
Height (with stand)	384.2 mm
Weight (with stand)	2.59 kg
Width (without stand)	504.3 mm
Depth (without stand)	49.6 mm
Height (without stand)	295.4 mm
Weight (without stand)	2.26 kg
Bezel width (side)	1.28 cm
Bezel width (top)	1.28 cm
Bezel width (bottom)	1.69 cm

Packaging data

Specification	Value
Package width	565.9 mm
Package depth	355 mm
Package height	119.8 mm
Package weight	4.14 kg

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, TCO
Doesn't contain	PVC/BFR

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	1.99
Carbon emissions, energy usage (kg of CO2e)	135.46
Carbon emissions, logistics (kg of CO2e)	34.36
Carbon emissions, manufacturing (kg of CO2e)	325.69
PAIA version	PAIA 1.3.0, 2021
Total carbon emissions, standard deviation (kg of CO2e)	121
Total carbon footprint (kg of CO2e)	498

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
