E Series E2020H computer monitor

49.5 cm (19.5") 1600 x 900 pixels HD+ LCD Black

Model E2020H

116 specifications Checked today

Display49.5 cm (19.5")
Resolution1600 x 900 pixels
Energy classD
ColourBlack
NVIDIA G-SYNCNo
Market positioningHome

See all specifications

Overview

Display: 49.5 cm (19.5")
Resolution: 1600 x 900 pixels
Energy class: D
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Home

Brand: Dell
Category: Monitor
Model: E2020H
Also known as: DELL E Series E2020H computer monitor 49.5 cm (19.5") 1600 x 900 pixels HD+ LCD Black

Specifications

116 specifications in 17 groups

Display

Specification	Value
Display diagonal	49.5 cm (19.5")
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	HD+
Panel type	TN
Backlight type	LED
Display brightness (typical)	250 cd/m²
Response time	5 ms
Screen shape	Flat
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900
Contrast ratio (typical)	1000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.27 x 0.27 mm
Pixel density	94 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	50 - 76 Hz
Viewable size, horizontal	43.3 cm
Viewable size, vertical	23.8 cm
Viewable size diagonal	49.5 cm
Sync-on-green (SOG)	Yes
High Dynamic Range (HDR) supported	No
DDC/CI	Yes
NTSC coverage (typical)	72%
Dell ComfortView technology	Yes
3D	No

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Home
Product colour	Black
Front bezel colour	Black
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
DVI port	No
HDMI	No
HDMI ports quantity	0
DisplayPorts quantity	1
DisplayPort version	1.2
Audio input	No
Headphone out	No
HDCP	Yes
AC (power) in	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	No
Pivot	No
Swivelling	No
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes
LED indicators	Power

Power

Specification	Value
Energy efficiency class (SDR)	D
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	10 kWh
Power consumption (typical)	9.9 W
Power consumption (standby)	0.2 W
Power consumption (max)	14 W
Power consumption (off)	0.3 W
Power consumption (PowerSave)	9.37 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	0.7 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	471.5 mm
Depth (with stand)	171 mm
Height (with stand)	369 mm
Weight (with stand)	2.63 kg
Width (without stand)	471.5 mm
Depth (without stand)	50.1 mm
Height (without stand)	275.4 mm
Weight (without stand)	2.2 kg
Bezel width (side)	1.83 cm
Bezel width (top)	1.83 cm
Bezel width (bottom)	1.83 cm

Packaging data

Specification	Value
Package width	118.1 mm
Package depth	581.9 mm
Package height	343.9 mm
Package weight	3.94 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort
Manual	Yes
DisplayPort cable length	1.8 m

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
Doesn't contain	PVC

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	1.2
Carbon emissions, energy usage (kg of CO2e)	74.99
Carbon emissions, logistics (kg of CO2e)	18.85
Carbon emissions, manufacturing (kg of CO2e)	305.96
PAIA version	PAIA 1.2.6, 2020
Total carbon emissions, standard deviation (kg of CO2e)	100
Total carbon footprint (kg of CO2e)	401

Other features

Specification	Value
On/off switch	Yes
TV tuner integrated	No
Compliance certificates	RoHS
Ethernet LAN (RJ-45) ports	0
Certification	TCO

Brand-specific features

Specification	Value
Dell Display Manager (DDM) compatibility	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
