LM22-L200N computer monitor
54.5 cm (21.4") 1920 x 1080 pixels Full HD LED Black
Model LM22-L200NPart no. DHI-LM22-L200NEAN 6923172509024
73 specifications Checked today
- Display54.5 cm (21.4")
- Resolution1920 x 1080 pixels
- Energy classE
- ColourBlack
- Operating hours (hours/days)24/7
- Built-in speaker(s)No
Overview
- Display
- 54.5 cm (21.4")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Colour
- Black
- Operating hours (hours/days)
- 24/7
- Built-in speaker(s)
- No
- Brand
- Dahua Technology
- Category
- Monitor
- Model
- LM22-L200N
- Part number
- DHI-LM22-L200N
- EAN / UPC
- 6923172509024
- Also known as
- Dahua Technology LM22-L200N computer monitor 54.5 cm (21.4") 1920 x 1080 pixels Full HD LED Black
Specifications
73 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 54.5 cm (21.4") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | VA |
| LED backlight | Yes |
| Backlight type | Edge LED |
| Display brightness (typical) | 250 cd/m² |
| Response time | 5 ms |
| Screen shape | Flat |
| Contrast ratio (typical) | 3000:1 |
| Maximum refresh rate | 100 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display diagonal (metric) | 54 cm |
| Colour depth | 8 bit |
| Colour gamut standard | NTSC |
| NTSC coverage (typical) | 72% |
Performance
| Specification | Value |
|---|---|
| Operating hours (hours/days) | 24/7 |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Frameless design | Yes |
| Front bezel colour | Black |
| Detachable stand | Yes |
| Feet colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| Headphone out | No |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Wall mountable | Yes |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15° |
| Plug and Play | Yes |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 15 kWh |
| Power consumption (typical) | 20.5 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 21 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Current rating | 2 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 493.1 mm |
| Depth (without stand) | 48.4 mm |
| Height (without stand) | 290.8 mm |
| Weight (without stand) | 2.3 kg |
| Bezel width (side) | 2 mm |
| Bezel width (top) | 2 mm |
| Bezel width (bottom) | 2.21 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 557 mm |
| Package depth | 140 mm |
| Package height | 370 mm |
| Package weight | 3.4 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
| Cables included | HDMI |
| Power adapter included | Yes |
| Quick start guide | Yes |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | CE |
| Mean time between failures (MTBF) | 30000 h |
Technical details
| Specification | Value |
|---|---|
| Native refresh rate | 60 Hz |
