Barco MDSC-2224 computer monitor

MDSC-2224 computer monitor

61 cm (24") 1920 x 1200 pixels LCD White

Model MDSC-2224Part no. K9307912

54 specifications Checked today

Display61 cm (24")
Resolution1920 x 1200 pixels
ColourWhite
Built-in cameraNo
Market positioningMedical
USB Type-A downstream ports quantity0

See all specifications

Overview

Display: 61 cm (24")
Resolution: 1920 x 1200 pixels
Colour: White
Built-in camera: No
Market positioning: Medical
USB Type-A downstream ports quantity: 0

Brand: Barco
Category: Monitor
Model: MDSC-2224
Part numbers: K9307912, K9307916
Also known as: Barco MDSC-2224 computer monitor 61 cm (24") 1920 x 1200 pixels LCD White

Specifications

54 specifications in 10 groups

Display

Specification	Value
Display diagonal	61 cm (24")
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Display technology	LCD
Touchscreen	No
Panel type	TFT
Display brightness (typical)	350 cd/m²
Response time	6 ms
Supported graphics resolutions	1920 x 1200 (WUXGA)
Aspect ratio	16:10
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.073 billion colours
Pixel pitch	0.270 x 0.270 mm
Digital horizontal frequency	0 - 90 kHz
Digital vertical frequency	0 - 75 Hz
Colour gamut standard	sRGB

Multimedia

Specification	Value
Built-in camera	No

Design

Specification	Value
Market positioning	Medical
Product colour	White

Ports & interfaces

Specification	Value
USB Type-A downstream ports quantity	0
VGA (D-Sub) ports quantity	0
DVI port	Yes
DVI-D ports quantity	1
DVI-I ports quantity	1
HDMI ports quantity	0
DisplayPorts quantity	1
HDCP	Yes
DC-in jack	Yes
Composite video in	1
Composite video out	1
Component video (YPbPr/YCbCr) in	1
S-Video inputs quantity	1

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	German, English, Spanish, French, Italian
Number of OSD languages	5

Power

Specification	Value
Power consumption (typical)	60 W
AC input voltage	100 - 250 V
AC input frequency	47/63 Hz

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width (without stand)	595 mm
Depth (without stand)	84 mm
Height (without stand)	414 mm
Weight (without stand)	7.7 kg

Packaging data

Specification	Value
Package weight	10 kg

Other features

Specification	Value
TV tuner integrated	No
Certification	CE, C-UL-US, DEMKO, CCC, IEC60601, IEC60601-1-2, EN55011 /CISPR 11, FCC CFR47, ROHS-2, REACH, WEEE
Supplied AC adapter type	LCD
