ProArt PQ22UC computer monitor
54.9 cm (21.6") 3840 x 2160 pixels 4K Ultra HD OLED Black, Grey
Model PQ22UCPart no. 90LM047E-B01370EAN 889349960271
67 specifications Checked today
- Display54.9 cm (21.6")
- Resolution3840 x 2160 pixels
- ColourBlack, Grey
- Built-in speaker(s)No
- Market positioningHome
- Power consumption (typical)38 W
Overview
- Display
- 54.9 cm (21.6")
- Resolution
- 3840 x 2160 pixels
- Colour
- Black, Grey
- Built-in speaker(s)
- No
- Market positioning
- Home
- Power consumption (typical)
- 38 W
- Brand
- ASUS
- Category
- Monitor
- Model
- PQ22UC
- Part number
- 90LM047E-B01370
- EAN / UPC
- 889349960271, 4718017203470
- Also known as
- ASUS ProArt PQ22UC computer monitor 54.9 cm (21.6") 3840 x 2160 pixels 4K Ultra HD OLED Black, Grey
Specifications
67 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 54.9 cm (21.6") |
| Display resolution | 3840 x 2160 pixels |
| Native aspect ratio | 16:9 |
| Display technology | OLED |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Display brightness (typical) | 330 cd/m² |
| Response time | 1 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 848 x 480, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1080, 2560 x 1440, 3 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.1245 x 0.1245 mm |
| Pixel density | 204 ppi |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| Colour depth | 10 bit |
| Adobe RGB coverage | 99.5% |
| 3D | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Home |
| Product colour | Black, Grey |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.2 |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | No |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Croatian, Czech, German, Dutch, English, Spanish, French, Hungarian, Indonesian, Italian, Japanese, Korean, Persian, Polish, Portuguese, Romanian, Russian, Thai, Turkish |
| Number of OSD languages | 21 |
| LED indicators | Power |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 38 W |
| Power consumption (standby) | 0.8 W |
| Power consumption (off) | 0.35 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 510.9 mm |
| Depth (with stand) | 128.2 mm |
| Height (with stand) | 382.1 mm |
| Weight (with stand) | 2.16 kg |
| Width (without stand) | 510.9 mm |
| Depth (without stand) | 8.5 mm |
| Height (without stand) | 313.9 mm |
| Weight (without stand) | 1.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 713 mm |
| Package depth | 182 mm |
| Package height | 576 mm |
| Package weight | 8.8 kg |
| Interface adapters included | HDMI female - micro HDMI male |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, USB |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| On/off switch | Yes |
| sRGB coverage (min) | 100% |
| Certification | UL/cUL, CB, ErP, FCC, ICES-3, CCC, CEL, BSMI, CU, RCM, VCCI, UkrSEPRO, J-MOSS, WEEE, PSE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85285210 |
