Designo MX27UC computer monitor
68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LED Black, Gold
Model MX27UCPart no. 90LM02B3-B01610EAN 4712900744781
75 specifications Checked today
- Display68.6 cm (27")
- Resolution3840 x 2160 pixels
- ColourBlack, Gold
- Game modeYes
- VESA mountingNo
- Power consumption (typical)35 W
Overview
- Display
- 68.6 cm (27")
- Resolution
- 3840 x 2160 pixels
- Colour
- Black, Gold
- Game mode
- Yes
- VESA mounting
- No
- Power consumption (typical)
- 35 W
- Brand
- ASUS
- Category
- Monitor
- Model
- MX27UC
- Part numbers
- 90LM02B3-B01610, 90LM02B3-B01670
- EAN / UPC
- 4712900744781, 889349463147, 889349599785, 4058154162538 +1 more
- Also known as
- ASUS Designo MX27UC computer monitor 68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LED Black, Gold
Specifications
75 specifications in 14 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 3840 x 2160 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | AH-IPS |
| Display brightness (typical) | 300 cd/m² |
| Response time | 5 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 3840 x 2160 |
| Aspect ratio | 4:3, 16:9 |
| Contrast ratio (typical) | 1300:1 |
| Contrast ratio (dynamic) | 100000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.155 x 0.155 mm |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| Digital horizontal frequency | 24 - 94 kHz |
| Digital vertical frequency | 40 - 76 Hz |
| Colour gamut standard | sRGB |
| 3D | No |
Performance
| Specification | Value |
|---|---|
| Game mode | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 6 W |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Gold |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB Type-A downstream ports quantity | 2 |
| USB Type-C downstream ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| PC Audio in | Yes |
| HDCP | Yes |
| DC-in jack | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | No |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | No |
| Pivot | No |
| Swivelling | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 35 W |
| Power consumption (off) | 0.5 W |
| Power consumption (PowerSave) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 614.4 mm |
| Depth (with stand) | 225.4 mm |
| Height (with stand) | 429.5 mm |
| Weight (with stand) | 5.5 kg |
| Weight (without stand) | 5.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 700 mm |
| Package depth | 120 mm |
| Package height | 537 mm |
| Package weight | 8 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DisplayPort, HDMI |
| Quick start guide | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| On/off switch | Yes |
| ECO mode | Yes |
| No flickering | No |
| Certification | Energy Star®, BSMI, CB, CCC, CEL level , CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), RCM, TUV Flicker-free , eStandby, TUV Low Blue Light |
| Supplied AC adapter type | AC |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85285210 |
