Fold OLED MQ17QH
Model Fold OLED MQ17QHPart no. 90LM09EV-B01170EAN 197105406223
72 specifications Checked today
- Display43.9 cm (17.3")
- Resolution2560 x 1920 pixels
- Energy classD
- ColourSilver
- NVIDIA G-SYNCNo
- Built-in USB hubYes
Overview
- Display
- 43.9 cm (17.3")
- Resolution
- 2560 x 1920 pixels
- Energy class
- D
- Colour
- Silver
- NVIDIA G-SYNC
- No
- Built-in USB hub
- Yes
- Brand
- ASUS
- Category
- Monitor
- Model
- Fold OLED MQ17QH
- Part number
- 90LM09EV-B01170
- EAN / UPC
- 197105406223, 4711387447307, 4711387447321
- Also known as
- ASUS ZenScreen Fold OLED MQ17QH computer monitor 43.9 cm (17.3") 2560 x 1920 pixels Quad HD Silver
Specifications
72 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.9 cm (17.3") |
| Display resolution | 2560 x 1920 pixels |
| Native aspect ratio | 4:3 |
| Display technology | OLED |
| Touchscreen | No |
| HD type | Quad HD |
| Panel type | OLED |
| Display brightness (peak) | 500 cd/m² |
| Display brightness (typical) | 350 cd/m² |
| Response time | 0.2 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Display surface | Gloss |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.137 x 0.137 mm |
| Viewable size, horizontal | 35.2 cm |
| Viewable size, vertical | 26.4 cm |
| Digital horizontal frequency | 24 - 83 kHz |
| Digital vertical frequency | 24 - 60 Hz |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | HDR True Black 500 |
| Colour depth | 10 bit |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 100% |
| DCI-P3 coverage | 100% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| Game mode | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB Type-C downstream ports quantity | 2 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI | No |
| Mini HDMI ports quantity | 1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | No |
| Cable lock slot | No |
| Height adjustment | No |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | D |
| Energy efficiency class (HDR) | E |
| Energy consumption (SDR) per 1000 hours | 11 kWh |
| Energy consumption (HDR) per 1000 hours | 14 kWh |
| Power consumption (typical) | 12 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Power consumption (PowerSave) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | External |
| Energy efficiency scale | A to G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 368.2 mm |
| Depth (with stand) | 9.7 mm |
| Height (with stand) | 286.8 mm |
| Weight (with stand) | 1.17 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 479 mm |
| Package depth | 103 mm |
| Package height | 362 mm |
| Package weight | 2.77 kg |
| Package type | Box |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, Forest Stewardship Council (FSC) Mix |
Other features
| Specification | Value |
|---|---|
| Certification | TÜV Flicker-free TÜV Low Blue Light VESA DisplayHDR 500 True Black |
Technical details
| Specification | Value |
|---|---|
| Native refresh rate | 60 Hz |
