PD49/96 computer monitor

124.5 cm (49") 5120 x 1440 pixels Dual QHD OLED Black, Silver

Model PD49/96

128 specifications Checked today

Display124.5 cm (49")
Resolution5120 x 1440 pixels
Energy classG
ColourBlack, Silver
NVIDIA G-SYNCYes
Market positioningGaming

See all specifications

Overview

Display: 124.5 cm (49")
Resolution: 5120 x 1440 pixels
Energy class: G
Colour: Black, Silver
NVIDIA G-SYNC: Yes
Market positioning: Gaming

Brand: AOC
Category: Monitor
Model: PD49/96
Part number: PD49/96
Also known as: AOC PD49/96 computer monitor 124.5 cm (49") 5120 x 1440 pixels Dual QHD OLED Black, Silver

Specifications

128 specifications in 14 groups

Display

Specification	Value
Display diagonal	124.5 cm (49")
Display resolution	5120 x 1440 pixels
Native aspect ratio	32:9
Display technology	OLED
Touchscreen	No
HD type	Dual QHD
Panel type	OLED
LED backlight	Yes
Backlight type	QD
Display brightness (typical)	1000 cd/m²
Response time	0.03 ms
Response time measurement type	GTG (Gray to Gray)
Display surface	Gloss
Screen shape	Curved
Screen curvature rating	1800R
Contrast ratio (typical)	150000:1
Contrast ratio (dynamic)	80000000:1
Maximum refresh rate	240 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.073 billion colours
Pixel pitch	0.233 x 0.233 mm
Pixel density	108.5 ppi
Horizontal scan range	30 - 390 kHz
Vertical scan range	48 - 240 Hz
Viewable size, horizontal	119.7 cm
Viewable size, vertical	33.9 cm
Display diagonal (metric)	124 cm
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR 400 True Black
DDC/CI	Yes
Surface hardness	2H
Colour gamut standard	Adobe RGB, DCI-P3, sRGB
sRGB coverage (typical)	144.4%
Adobe RGB coverage	98.1%
BT.2020 coverage	83.4%
DCI-P3 coverage	98.5%

Performance

Specification	Value
NVIDIA G-SYNC	Yes
AMD FreeSync	Yes
NVIDIA G-SYNC type	G-SYNC Compatible
AMD FreeSync type	FreeSync Premium Pro
AMD FreeSync refresh rate range	48 - 240 Hz
VESA Adaptive Sync support	Yes
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	16 W
Built-in camera	No

Design

Specification	Value
Market positioning	Gaming
Product colour	Black, Silver
Frameless design	Yes
Front bezel colour	Black
Detachable stand	Yes

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C, USB Type-B
Number of USB Type-B upstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W
HDMI	Yes
HDMI ports quantity	2
HDMI version	2.1
DisplayPorts quantity	1
DisplayPort version	1.4
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
Built-in KVM switch	Yes

Network

Specification	Value
Ethernet LAN	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	13 cm
Swivelling	Yes
Swivel angle range	20 - 20°
Tilt adjustment	Yes
Tilt angle range	3 - 13°
Picture-in-Picture	Yes
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Croatian, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Ukrainian

Power

Specification	Value
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	65 kWh
Energy consumption (HDR) per 1000 hours	75 kWh
Power consumption (typical)	130 W
Power consumption (standby)	0.5 W
Power consumption (max)	330 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	4.5 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	10 - 85%
Storage relative humidity (H-H)	5 - 93%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	1191.8 mm
Depth (with stand)	388.3 mm
Height (with stand)	561.5 mm
Weight (with stand)	15.8 kg
Width (without stand)	1191.8 mm
Depth (without stand)	160.7 mm
Height (without stand)	373.8 mm
Weight (without stand)	11.2 kg

Packaging data

Specification	Value
Package width	1310 mm
Package depth	565 mm
Package height	506 mm
Package weight	29.5 kg

Packaging content

Specification	Value
Cables included	AC, HDMI, DisplayPort, USB, USB Type-C

Sustainability

Specification	Value
Doesn't contain	Mercury, PVC/BFR

Other features

Specification	Value
Brand specific technologies	Crosshair
Low input lag	Yes
FPS counter	Yes
Dial point	Yes
Shadow control	Yes
Bezel thickness type	Frameless
Compliance certificates	WEEE, REACH, RoHS
Certification	WEEE,REACH compliant,RoHs compliant
Warranty period	3 year(s)
