AOC P1 22P1 computer monitor

54.6 cm (21.5") 1920 x 1080 pixels Full HD LED Black

Model 22P1EAN 4038986126205

134 specifications Checked 2 days ago

Display54.6 cm (21.5")
Resolution1920 x 1080 pixels
Energy classE
ColourBlack
NVIDIA G-SYNCNo
Built-in speaker(s)Yes

See all specifications

Overview

Display: 54.6 cm (21.5")
Resolution: 1920 x 1080 pixels
Energy class: E
Colour: Black
NVIDIA G-SYNC: No
Built-in speaker(s): Yes

Brand: AOC
Category: Monitor
Model: 22P1
Part number: 22P1
EAN / UPC: 4038986126205, 4717385944879
Also known as: AOC P1 22P1 computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LED Black

Specifications

134 specifications in 15 groups

Display

Specification	Value
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Full HD
Panel type	MVA
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	5 ms
Response time measurement type	GTG (Gray to Gray)
Display surface	Matt
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Supported video modes	1080p
Aspect ratio	16:9
Contrast ratio (typical)	3000:1
Contrast ratio (dynamic)	50000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.2479 x 0.2479 mm
Horizontal scan range	30 - 83 kHz
Vertical scan range	50 - 76 Hz
Viewable size, horizontal	47.6 cm
Viewable size, vertical	26.8 cm
Digital horizontal frequency	30 - 83 kHz
Display diagonal (metric)	54.61 cm
Surface hardness	3H
Colour depth	6 bit
Colour gamut standard	Adobe RGB, sRGB
sRGB coverage (typical)	102%
Adobe RGB coverage	72%
3D	No
Separate H/V sync	Yes

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Fast charging	Yes
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	4 W
Built-in camera	No
Built-in microphone	No

Design

Specification	Value
Market positioning	Business
Product colour	Black
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	4
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DisplayPort version	1.2
Audio input	Yes
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
Microphone in	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Height adjustment	Yes
Adjustable height (max)	13 cm
Pivot	Yes
Pivot angle	1 - 90°
Swivelling	Yes
Swivel angle range	-175 - 175°
Tilt adjustment	Yes
Tilt angle range	-5 - 23°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Croatian, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Ukrainian
Number of OSD languages	16
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	16 kWh
Power consumption (typical)	14.2 W
Power consumption (standby)	0.28 W
Power consumption (off)	0.22 W
Power consumption (PowerSave)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal
Energy efficiency scale	A to G
External power adapter	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	10 - 85%
Storage relative humidity (H-H)	5 - 93%
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	504.4 mm
Depth (with stand)	198.8 mm
Height (with stand)	506 mm
Weight (with stand)	4.31 kg
Width (without stand)	305.5 mm
Depth (without stand)	47 mm
Height (without stand)	504.4 mm
Weight (without stand)	2.53 kg

Packaging data

Specification	Value
Package width	715 mm
Package depth	159 mm
Package height	387 mm
Package weight	6.2 kg
Package type	Box
USB cable length	1.8 m

Packaging content

Specification	Value
Cables included	AC, HDMI, DisplayPort
Audio cable length	1.5 m
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m
Power cable length	1.8 m

Sustainability

Specification	Value
Sustainability certificates	EPEAT Silver, TCO
Doesn't contain	Mercury, PVC/BFR

Other features

Specification	Value
Compatibility	VESA-P1
On/off switch	Yes
TV tuner integrated	No
Exterior finish type	Textured
Bezel thickness type	Normal
Compliance certificates	CE
Heavy metals free	Hg (mercury)
Mean time between failures (MTBF)	50000 h
Light effects	No
Certification	WEEE,REACH compliant,RoHs compliant,CB,TUV-GS-Mark,ISO 9241-307,EAC,FCC,Microsoft WHQL
Warranty period	3 year(s)

Recycling data

Specification	Value
Packaging recyclability rate	100%

Logistics data

Specification	Value
Harmonized System (HS) code	85285210

Energy efficiency

ENERGY STAR certified

Displays · model 22E1 · certified Jan 7, 2020 · United States, Japan, Canada, Taiwan

Measurement	Value
On-mode power	13.12 W
Sleep-mode power	0.29 W
Off-mode power	0.13 W
