2230Fa computer monitor
55.9 cm (22") 1680 x 1050 pixels Black
Model 2230FaPart no. 2230FAEAN 685417021383
35 specifications Checked today
- Display55.9 cm (22")
- Resolution1680 x 1050 pixels
- ColourBlack
- Mac operating systems supportedYes
- RMS rated power4 W
- USB Type-A downstream ports quantity0
Overview
- Display
- 55.9 cm (22")
- Resolution
- 1680 x 1050 pixels
- Colour
- Black
- Mac operating systems supported
- Yes
- RMS rated power
- 4 W
- USB Type-A downstream ports quantity
- 0
- Brand
- AOC
- Category
- Monitor
- Model
- 2230Fa
- Part number
- 2230FA
- EAN / UPC
- 685417021383, 4711200990676
- Also known as
- AOC 2230Fa computer monitor 55.9 cm (22") 1680 x 1050 pixels Black
Specifications
35 specifications in 10 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 55.9 cm (22") |
| Display resolution | 1680 x 1050 pixels |
| Touchscreen | No |
| Display brightness (typical) | 300 cd/m² |
| Response time | 2 ms |
| Supported video modes | 1080i, 720p |
| Contrast ratio (dynamic) | 20000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Pixel pitch | 0.282 x 0.282 mm |
| Horizontal scan range | 24 - 80 kHz |
| Vertical scan range | 56 - 75 Hz |
Performance
| Specification | Value |
|---|---|
| Mac operating systems supported | Yes |
Multimedia
| Specification | Value |
|---|---|
| RMS rated power | 4 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| USB Type-A downstream ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
| DVI-I ports quantity | 0 |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Tilt angle range | -5 - 20° |
| Plug and Play | Yes |
| LED indicators | Stand-by |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 49 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 510 mm |
| Depth (without stand) | 220 mm |
| Height (without stand) | 417 mm |
| Weight (without stand) | 5.2 kg |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 562 x 454 x 132 mm |
| Package weight | 6.7 kg |
Other features
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| Power requirements | 100~240V AC, 50/60Hz |
| Safety | cULus, FCC, CE, RoHS |
