AW3423DW computer monitor

86.8 cm (34.2") 3440 x 1440 pixels Quad HD OLED White, Black

Model AW3423DWPart no. GAME-AW3423DWEAN 5397184567784

118 specifications Checked today

Display86.8 cm (34.2")
Resolution3440 x 1440 pixels
Energy classG
ColourWhite, Black
NVIDIA G-SYNCYes
Built-in speaker(s)No

See all specifications

Overview

Display: 86.8 cm (34.2")
Resolution: 3440 x 1440 pixels
Energy class: G
Colour: White, Black
NVIDIA G-SYNC: Yes
Built-in speaker(s): No

Brand: Alienware
Category: Monitor
Model: AW3423DW
Part numbers: GAME-AW3423DW, AW3423DW
EAN / UPC: 5397184567784, 884116442493
Also known as: Alienware AW3423DW computer monitor 86.8 cm (34.2") 3440 x 1440 pixels Quad HD OLED White, Black

Specifications

118 specifications in 15 groups

Display

Specification	Value
Display diagonal	86.8 cm (34.2")
Display resolution	3440 x 1440 pixels
Native aspect ratio	21:9
Display technology	OLED
Touchscreen	No
HD type	Quad HD
Display brightness (typical)	250 cd/m²
Response time	0.1 ms
Anti-glare screen	Yes
Screen shape	Curved
Screen curvature rating	1800R
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440
Supported video modes	480p, 576p, 720p, 1080p
Contrast ratio (typical)	1000000:1
Contrast ratio (dynamic)	1000000:1
Maximum refresh rate	175 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Pixel pitch	0.23 x 0.23 mm
Pixel density	110 ppi
Viewable size, horizontal	80 cm
Viewable size, vertical	33.7 cm
Viewable size diagonal	86.8 cm
Display diagonal (metric)	86.82 cm
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 400
DDC/CI	Yes
Colour depth	10 bit
Colour gamut standard	DCI-P3
Colour gamut	99.3%
sRGB coverage (typical)	149%
Heat dissipation	684 BTU/h
Heat dissipation (typical)	144.67 BTU/h

Performance

Specification	Value
NVIDIA G-SYNC	Yes
AMD FreeSync	Yes
NVIDIA G-SYNC type	G-SYNC ULTIMATE
Flicker-free technology	Yes
Low Blue Light technology	Yes
Smart modes	RPG, Sports

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Gaming
Product colour	White, Black
Front bezel colour	Black
Detachable stand	Yes

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
USB Type-A downstream ports quantity	4
DVI port	No
HDMI	Yes
HDMI ports quantity	2
HDMI version	2.0
DisplayPorts quantity	1
DisplayPort version	1.4
Audio output	Yes
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDCP	Yes

Network

Specification	Value
Wi-Fi	No

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	11 cm
Pivot	No
Swivelling	Yes
Swivel angle range	-20 - 20°
Tilt adjustment	Yes
Tilt angle range	-5 - 21°
On Screen Display (OSD)	Yes
Plug and Play	Yes
LED indicators	Yes

Power

Specification	Value
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	34 kWh
Energy consumption (HDR) per 1000 hours	36 kWh
Power consumption (typical)	42.3 W
Power consumption (standby)	0.5 W
Power consumption (max)	200 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	3 A
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	815.2 mm
Depth (with stand)	305.7 mm
Height (with stand)	415.6 mm
Weight (with stand)	9.88 kg
Width (without stand)	815.2 mm
Depth (without stand)	137.1 mm
Height (without stand)	364.1 mm
Weight (without stand)	6.92 kg
Bezel width (side)	1.1 cm
Bezel width (top)	4.65 mm
Bezel width (bottom)	2.06 cm

Packaging data

Specification	Value
Package weight	15.9 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	DisplayPort, DisplayPort to Mini DisplayPort, HDMI, USB Type-A
Quick start guide	Yes
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
Doesn't contain	Arsenic

Other features

Specification	Value
Compliance certificates	RoHS
Heavy metals free	Hg (mercury)
Ethernet LAN (RJ-45) ports	0
Power management	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
