TM-22 computer monitor

54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD Touchscreen Multi-user Black

Model TM-22Part no. TM220011E0100EAN 813086002987

91 specifications Checked today

Display54.6 cm (21.5")
Resolution1920 x 1080 pixels
Energy classE
OSWindows 10
ColourBlack
NVIDIA G-SYNCNo

See all specifications

Overview

Display: 54.6 cm (21.5")
Resolution: 1920 x 1080 pixels
Energy class: E
OS: Windows 10
Colour: Black
NVIDIA G-SYNC: No

Brand: AG Neovo
Category: Monitor
Model: TM-22
Part number: TM220011E0100
EAN / UPC: 813086002987, 4710739592429
Also known as: AG Neovo TM-22 computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD Touchscreen Multi-user Black

Specifications

91 specifications in 14 groups

Display

Specification	Value
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	Yes
HD type	Full HD
Panel type	TN
Backlight type	LED
Touchscreen type	Multi-user
Touchscreen technology	Capacitive
Touch technology	Multi-touch
Number of simultaneous touchpoints	10
Display brightness (typical)	250 cd/m²
Response time	3 ms
Screen shape	Flat
Contrast ratio (typical)	20000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.248 x 0.248 mm
Viewable size diagonal	54.6 cm
Digital horizontal frequency	30 - 83 kHz
Digital vertical frequency	55 - 75 Hz
Display diagonal (metric)	55 cm
Surface hardness	7H

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Operating hours (hours/days)	24/7
Operating system installed	Windows 10

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	2 W
Built-in camera	No
Built-in microphone	No

Design

Specification	Value
Market positioning	Business
Product colour	Black
Glass thickness	2.4 mm

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	4
VGA (D-Sub) ports quantity	1
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.3
DisplayPorts quantity	1
Audio input	1
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Wall mountable	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	38.7 cm
Tilt adjustment	Yes
Tilt angle range	-5 - 90°
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	14 kWh
Power consumption (typical)	22 W
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	10 - 85%
Storage relative humidity (H-H)	5 - 93%

Weight & dimensions

Specification	Value
Width (with stand)	522.4 mm
Depth (with stand)	238.5 mm
Height (with stand)	387.4 mm
Weight (with stand)	6.3 kg
Width (without stand)	522.4 mm
Depth (without stand)	57.2 mm
Height (without stand)	318.4 mm
Weight (without stand)	3.9 kg

Packaging data

Specification	Value
Package width	586 mm
Package depth	186 mm
Package height	422 mm
Package weight	8.1 kg

Packaging content

Specification	Value
Cables included	AC, Audio (3.5mm), HDMI, USB

Other features

Specification	Value
Compliance certificates	CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Certification	FCC, CE, LVD, WEEE, RoHS, REACH, EAC, UKCA

Technical details

Specification	Value
Native refresh rate	60 Hz

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
