AG Neovo DR22-KIT computer monitor

DR22-KIT computer monitor

54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD White

Model DR22-KIT

63 specifications Checked today

Display54.6 cm (21.5")
Resolution1920 x 1080 pixels
Energy classA
ColourWhite
Built-in speaker(s)Yes
Market positioningMedical

See all specifications

Overview

Display: 54.6 cm (21.5")
Resolution: 1920 x 1080 pixels
Energy class: A
Colour: White
Built-in speaker(s): Yes
Market positioning: Medical

Brand: AG Neovo
Category: Monitor
Model: DR22-KIT
Part number: DR22-KIT
Also known as: AG Neovo DR22-KIT computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD White

Specifications

63 specifications in 10 groups

Display

Specification	Value
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	TFT
Backlight type	LED
Display brightness (typical)	250 cd/m²
Response time	3 ms
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Aspect ratio	16:9
Contrast ratio (dynamic)	2000000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.2482 x 0.2482 mm
Horizontal scan range	30 - 82 kHz
Vertical scan range	56 - 75 Hz
3D	No

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	3 W
Built-in camera	No

Design

Specification	Value
Market positioning	Medical
Product colour	White

Ports & interfaces

Specification	Value
Built-in USB hub	No
USB Type-A downstream ports quantity	0
USB Type-C downstream ports quantity	0
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI	Yes
HDMI ports quantity	1
Headphone out	Yes
Headphone outputs	1
DC-in jack	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	75 x 75,100 x 100 mm
Cable lock slot	No
Height adjustment	No

Power

Specification	Value
Power consumption (typical)	25 W
Power consumption (standby)	3 W
Power consumption (off)	1 W
Annual energy consumption	27 kWh

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Weight (with stand)	6.9 kg
Width (without stand)	513 mm
Depth (without stand)	155 mm
Height (without stand)	369 mm
Weight (without stand)	6.3 kg

Packaging data

Specification	Value
Package width	602 mm
Package depth	212 mm
Package height	476 mm
Package weight	9 kg

Other features

Specification	Value
TV tuner integrated	No
Compliance certificates	RoHS
Energy efficiency class (legacy scale)	A
Certification	FCC, CE, RoHS, WEEE, REACH, GOST-R
