AG Neovo 22" Widescreen LCD Display E-W22

22" Widescreen LCD Display E-W22

Model 22" Widescreen LCD Display E-W22Part no. E-W22

36 specifications Checked today

Display55.9 cm (22")
Resolution1680 x 1050 pixels
ColourBlack
Built-in speaker(s)Yes
VGA (D-Sub) ports quantity1
Panel mounting interface100 x 100 mm

See all specifications

Overview

Display: 55.9 cm (22")
Resolution: 1680 x 1050 pixels
Colour: Black
Built-in speaker(s): Yes
VGA (D-Sub) ports quantity: 1
Panel mounting interface: 100 x 100 mm

Brand: AG Neovo
Category: Monitor
Model: 22" Widescreen LCD Display E-W22
Part number: E-W22
Also known as: AG Neovo 22" Widescreen LCD Display E-W22 computer monitor 55.9 cm (22") 1680 x 1050 pixels Black

Specifications

36 specifications in 8 groups

Display

Specification	Value
Display diagonal	55.9 cm (22")
Display resolution	1680 x 1050 pixels
Touchscreen	No
Display brightness (typical)	300 cd/m²
Response time	3 ms
Contrast ratio (typical)	900:1
Contrast ratio (dynamic)	3000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Pixel pitch	0.282
Horizontal scan range	24 - 80 kHz
Vertical scan range	55 - 76 Hz
Surface treatment	Hard Coating (3H), Anti-glare

Multimedia

Specification	Value
Built-in speaker(s)	Yes
RMS rated power	4 W

Design

Specification	Value
Product colour	Black

Ports & interfaces

Specification	Value
VGA (D-Sub) ports quantity	1
DVI-D ports quantity	1
Audio input	Yes
Audio output	Yes
Headphone connectivity	3.5 mm
HDCP	Yes

Ergonomics

Specification	Value
Panel mounting interface	100 x 100 mm
Tilt angle range	5 - 25°
LED indicators	Stand-by

Power

Specification	Value
Power consumption (typical)	55 W
Power consumption (standby)	2 W
Power consumption (off)	1 W

Weight & dimensions

Specification	Value
Width (without stand)	512 mm
Depth (without stand)	196 mm
Height (without stand)	416 mm
Weight (without stand)	7.9 kg

Other features

Specification	Value
Power requirements	100 - 240V, 50 - 60Hz
Mean time between failures (MTBF)	50000 h
Certification	UL/CUL, FCC, NOM, CB, CE, TUV/Baurt, NORDIC, BSMI, EPA, GOST-R/HYGIENIC, WEEE, RoHS
Dimensions (W x D x H) (imperial)	15087.6 x 5181.6 x 14325.6 mm (594 x 204 x 564")
