V196L B
Model V196L BPart no. UM.CV6EE.B23EAN 4711121888755
57 specifications Checked today
- Display48.3 cm (19")
- Resolution1280 x 1024 pixels
- Energy classE
- ColourBlack
- Built-in speaker(s)Yes
- Market positioningBusiness
Overview
- Display
- 48.3 cm (19")
- Resolution
- 1280 x 1024 pixels
- Energy class
- E
- Colour
- Black
- Built-in speaker(s)
- Yes
- Market positioning
- Business
- Brand
- Acer
- Category
- Monitor
- Model
- V196L B
- Part numbers
- UM.CV6EE.B23, UM.CV6AA.B04, UM.CV6EE.B21
- EAN / UPC
- 4711121888755, 4711121898839, 195133236942
- Also known as
- Acer V196L B computer monitor 48.3 cm (19") 1280 x 1024 pixels SXGA LCD Black
Specifications
57 specifications in 9 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 48.3 cm (19") |
| Display resolution | 1280 x 1024 pixels |
| Native aspect ratio | 5:4 |
| Display technology | LCD |
| Touchscreen | No |
| HD type | SXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Display brightness (typical) | 250 cd/m² |
| Response time | 5 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 100000000:1 |
| Maximum refresh rate | 75 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.29 x 0.29 mm |
| Horizontal scan range | 30 - 80 kHz |
| Vertical scan range | 55 - 75 Hz |
| Viewable size, horizontal | 37.6 cm |
| Viewable size, vertical | 30.1 cm |
| Display diagonal (metric) | 48.3 cm |
| Colour depth | 6 bit |
| NTSC coverage (typical) | 72% |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Wall mountable | Yes |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 25° |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 14 kWh |
| Power consumption (typical) | 18 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency scale | A to G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 406.4 mm |
| Depth (with stand) | 191 mm |
| Height (with stand) | 422.7 mm |
| Weight (with stand) | 3.1 kg |
| Width (without stand) | 406.4 mm |
| Depth (without stand) | 52 mm |
| Height (without stand) | 337 mm |
| Weight (without stand) | 2.66 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
| Cables included | HDMI |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | TCO |
