Acer B196L ymdr

B196L ymdr

Model B196L ymdrPart no. UM.CB6AA.001EAN 809392590133

45 specifications Checked today

Display48.3 cm (19")
Resolution1280 x 1024 pixels
Energy classF
ColourBlack
Built-in speaker(s)Yes
USB Type-A downstream ports quantity0

See all specifications

Overview

Display: 48.3 cm (19")
Resolution: 1280 x 1024 pixels
Energy class: F
Colour: Black
Built-in speaker(s): Yes
USB Type-A downstream ports quantity: 0

Brand: Acer
Category: Monitor
Model: B196L ymdr
Part number: UM.CB6AA.001
EAN / UPC: 809392590133, 132018263167, 807320196815, 887899122453 +1 more
Also known as: Acer Professional B196L ymdr computer monitor 48.3 cm (19") 1280 x 1024 pixels Black

Specifications

45 specifications in 11 groups

Display

Specification	Value
Display diagonal	48.3 cm (19")
Display resolution	1280 x 1024 pixels
Native aspect ratio	16:9
Touchscreen	No
Display brightness (typical)	250 cd/m²
Response time	5 ms
Supported graphics resolutions	1280 x 1024 (SXGA)
Aspect ratio	16:9
Contrast ratio (dynamic)	100000000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
3D	No

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Built-in camera	No

Design

Specification	Value
Product colour	Black

Ports & interfaces

Specification	Value
USB Type-A downstream ports quantity	0
VGA (D-Sub) ports quantity	1
DVI port	Yes
HDMI ports quantity	0
HDCP	Yes
AC (power) in	Yes

Ergonomics

Specification	Value
Cable lock slot	No
Height adjustment	Yes
LED indicators	Power

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy consumption (SDR) per 1000 hours	18 kWh
Power consumption (typical)	15.8 W
Power consumption (standby)	0.45 W
Power consumption (off)	0.35 W
AC input voltage	110 - 220 V
Energy efficiency scale	A to G

Weight & dimensions

Specification	Value
Width (with stand)	406.4 mm
Depth (with stand)	221 mm
Height (with stand)	519.1 mm
Weight (with stand)	5.3 kg
Width (without stand)	406.4 mm
Depth (without stand)	50.8 mm
Height (without stand)	337.8 mm
Weight (without stand)	2.8 kg

Packaging content

Specification	Value
Cables included	AC, DVI, VGA

Sustainability

Specification	Value
Sustainability certificates	EPEAT Gold

Other features

Specification	Value
TV tuner integrated	No
Supplied AC adapter type	LCD

Thin Client

Specification	Value
Thin client installed	No
