Samsung CLP-680ND laser printer Colour
9600 x 600 DPI A4
Model CLP-680NDPart no. CLP-680ND/XAXEAN 8806071948591
75 specifications
- ProcessorARM Cortex
- Memory256 MB
- Weight20 kg
- ColourYes
- Maximum duty cycle60000 pages per month
- Total number of input trays1
Overview
- Processor
- ARM Cortex
- Memory
- 256 MB
- Weight
- 20 kg
- Colour
- Yes
- Maximum duty cycle
- 60000 pages per month
- Total number of input trays
- 1
- Brand
- Samsung
- Category
- Laser Printer
- Model
- CLP-680ND
- Part numbers
- CLP-680ND/XAX, CLP-680ND
- EAN / UPC
- 8806071948591, 635753728088, 640206656054, 823019779077 +7 more
- Also known as
- Samsung CLP-680ND laser printer Colour 9600 x 600 DPI A4
Specifications
75 specifications in 13 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Print technology | Laser |
| Duplex printing | Yes |
| Maximum resolution | 9600 x 600 DPI |
| Print speed (black, normal quality, A4/US Letter) | 24 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 25 ppm |
| Print speed (black, draft quality, A4/US Letter) | 24 ppm |
| Print speed (colour, draft quality, A4/US Letter) | 25 ppm |
| Time to first page (black, normal) | 17 s |
| Time to first page (colour, normal) | 17 s |
| Economical printing | Yes |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 60000 pages per month |
| Recommended duty cycle | 0 - 60000 pages per month |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Number of print cartridges | 4 |
| Page description languages | PCL 5e, PCL 6, PDF 1.7, PostScript 3, SPL-C |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 250 sheets |
| Total output capacity | 150 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 50 sheets |
| Maximum input capacity | 820 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Maximum print size | 216 x 356 mm |
| Paper tray media types | Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper, Pre-printed, Recycled paper, Thick paper, Thin paper, Transparencies |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5 |
| Non-ISO print media sizes | Executive, Folio, Index card, Letter, Oficio, Statement |
| JIS B-series sizes (B0...B9) | B5 |
| Envelopes sizes | 7 3/4, 9, 10, C5, C6, DL |
| Custom media width | 76 - 216 mm |
| Custom media length | 127 - 356 mm |
| Paper tray media weight | 60 - 220 g/m² |
| Multi-Purpose Tray media weight | 60 - 220 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Ethernet, USB 2.0 |
| Direct printing | Yes |
| Optional connectivity | Parallel |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Network ready | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Mobile printing technologies | Samsung Mobile Print |
Performance
| Specification | Value |
|---|---|
| Internal memory | 256 MB |
| Maximum internal memory | 512 MB |
| Built-in processor | Yes |
| Processor family | ARM Cortex |
| Processor model | ARM11/ARM9 |
| Processor frequency | 533 MHz |
| Sound pressure level (printing) | 52 dB |
| Sound power level (standby) | 32 dB |
Design
| Specification | Value |
|---|---|
| Product colour | Brown, White |
| Built-in display | Yes |
| Display | LCD |
| Display number of lines | 2 lines |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 450 W |
| Power consumption (standby) | 14 W |
| Power consumption (off) | 1 W |
| Energy Star Typical Electricity Consumption (TEC) | 1.49 kWh/week |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista |
| Mac operating systems supported | Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 420 mm |
| Depth | 311.3 mm |
| Height | 452.5 mm |
| Weight | 20 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 513 mm |
| Package depth | 434 mm |
| Package height | 346 mm |
| Package weight | 14 kg |
Other features
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Power LED | Yes |
| Stand-by LED | Yes |
