ECOSYS PA2001w
1800 x 600 DPI A4 Wi-Fi
Model PA2001wPart no. 1102YV3NL0EAN 632983069592
72 specifications
- Memory32 MB
- Storage0 GB
- Weight4.5 kg
- ColourNo
- Maximum duty cycle8000 pages per month
- Total number of input trays1
Overview
- Memory
- 32 MB
- Storage
- 0 GB
- Weight
- 4.5 kg
- Colour
- No
- Maximum duty cycle
- 8000 pages per month
- Total number of input trays
- 1
- Brand
- Kyocera
- Category
- Laser Printer
- Model
- PA2001w
- Part number
- 1102YV3NL0
- EAN / UPC
- 632983069592
- Also known as
- KYOCERA ECOSYS PA2001w 1800 x 600 DPI A4 Wi-Fi
Specifications
72 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Print technology | Laser |
| Duplex printing | Yes |
| Duplex printing mode | Manual |
| Maximum resolution | 1800 x 600 DPI |
| Print speed (black, normal quality, A4/US Letter) | 20 ppm |
| Warm-up time | 20 s |
| Time to first page (black, normal) | 8 s |
| Economical printing | Yes |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 8000 pages per month |
| Recommended duty cycle | 200 - 500 pages per month |
| Printing colours | Black |
| Number of print cartridges | 1 |
| Page description languages | GDI |
| Country of origin | Vietnam |
| Replacement cartridges | TK-1248 tonerkit (1.500 pagina's) DK-1248 Drumeenheid (10.000 pagina's) |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 150 sheets |
| Total output capacity | 50 sheets |
| Multi-Purpose tray | No |
| Maximum input capacity | 150 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Maximum print size | 216 x 356 mm |
| Paper tray media types | Plain paper |
| ISO A-series sizes (A0...A9) | A4, A5 |
| ISO B-series sizes (B0...B9) | B5 |
| Non-ISO print media sizes | 16K, Legal, Letter |
| Custom media length | 148 - 356 mm |
| Paper tray media weight | 65 - 105 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Direct printing | No |
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | No |
| Network ready | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | No |
| Near Field Communication (NFC) | No |
| Mobile printing technologies | Kyocera Mobile Print |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32 MB |
| Maximum internal memory | 32 MB |
| Internal storage capacity | 0 GB |
| Card reader integrated | No |
| Built-in processor | Yes |
| Sound pressure level (printing) | 52 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | Black |
| Built-in display | No |
| Control type | Buttons |
| Certification | TÜV/GS, CE |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 330 W |
| Power consumption (max) | 700 W |
| Power consumption (ready) | 2.3 W |
| Power consumption (PowerSave) | 0.4 W |
| Energy Star Typical Electricity Consumption (TEC) | 0.23 kWh/week |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 350 mm |
| Depth | 233 mm |
| Height | 177 mm |
| Weight | 4.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 426 mm |
| Package depth | 309 mm |
| Package height | 342 mm |
| Package weight | 6.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Included cartridge capacity (black) | 700 pages |
| Cables included | AC, USB |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
