HP LaserJet Enterprise M506x
1200 x 1200 DPI A4
Model M506xPart no. F2A70A#BGJ-06EAN 725184104978
65 specifications
- Display10.9 cm (4.3")
- Memory512 MB
- Weight15.8 kg
- ColourNo
- Maximum duty cycle150000 pages per month
- Total number of input trays2
Overview
- Display
- 10.9 cm (4.3")
- Memory
- 512 MB
- Weight
- 15.8 kg
- Colour
- No
- Maximum duty cycle
- 150000 pages per month
- Total number of input trays
- 2
- Brand
- HP
- Category
- Laser Printer
- Model
- M506x
- Part numbers
- F2A70A#BGJ-06, F2A70A, F2A70AR, F2A70A#BNDL, F2A70A#CRAZY, F2A70A/GOLD +6 more
- EAN / UPC
- 725184104978, 779184029090, 888793425794, 888793425800 +16 more
- Also known as
- HP LaserJet Enterprise M506x 1200 x 1200 DPI A4
Specifications
65 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Print technology | Laser |
| Duplex printing | Yes |
| Duplex printing mode | Auto |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 43 ppm |
| Time to first page (black, normal) | 5.9 s |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 150000 pages per month |
| Recommended duty cycle | 2000 - 7500 pages per month |
| Printing colours | Black |
| Number of print cartridges | 1 |
| Page description languages | PCL 5, PCL 6, PDF 1.7, PostScript 3 |
| HP segment | Enterprise |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 2 |
| Total input capacity | 1200 sheets |
| Total output capacity | 250 sheets |
| Paper tray 2 input capacity | 550 sheets |
| Paper input type | Paper tray |
| Maximum number of input trays | 3 |
| Maximum input capacity | 2300 sheets |
| Maximum output capacity | 250 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Envelopes, Transparencies, Bond paper, Card stock, Plain paper, Pre-printed, Labels, Recycled paper |
| ISO A-series sizes (A0...A9) | A5, A4 |
| JIS B-series sizes (B0...B9) | B5 |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Ethernet, USB 2.0 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Network ready | Yes |
| Mobile printing technologies | Apple AirPrint, HP ePrint, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 512 MB |
| Maximum internal memory | 1536 MB |
| Memory slots | 1 |
| Memory type | DDR3 |
| Built-in processor | Yes |
| Processor frequency | 1200 MHz |
| Sound pressure level (printing) | 54 dB |
| Sound pressure level (quiet mode) | 24 dB |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Touchscreen | Yes |
| Control type | Touch |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 741.98 W |
| Power consumption (standby) | 13.72 W |
| Power consumption (off) | 0.08 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 15 - 32.5 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | EPEAT Silver, ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 418 mm |
| Depth | 376 mm |
| Height | 481 mm |
| Weight | 15.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 564 mm |
| Package depth | 498 mm |
| Package height | 713 mm |
| Package weight | 22.1 kg |
