Via HP Jetdirect print servers: TCP/IP (IP Direct mode; may require software from the NOS vendor or third party vendor: LPD, FTP, IPP), IPX/SPX, DLC/LLC, AppleTalk, Auto-IP, Apple Rendezvous compatible, NDS, Bindery, NCP, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP (v 1, 2c, 3), HTTP; not all protocol
Performance
Specification
Value
Internal memory
128 MB
Maximum internal memory
512 MB
Built-in processor
Yes
Processor model
MIPS 20KC
Processor frequency
533 MHz
Power
Specification
Value
Power consumption (printing)
200 W
Power consumption (off)
0.5 W
System requirements
Specification
Value
Minimum system requirements for Macintosh
Mac OS 8.6, 9.0, 9.04, 9.1, 9.2, 10.1, 4 MB of free RAM space and 160 MB free hard disk space; AppleTalk
Operational conditions
Specification
Value
Operating temperature (T-T)
10 - 32.5 °C
Storage temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80%
Storage relative humidity (H-H)
10 - 90%
Weight & dimensions
Specification
Value
Weight
69.4 kg
Dimensions (WxDxH)
638 x 600 x 633 mm
Maximum dimensions (W x D x H)
1397 x 1001 x 1036 mm
Pallet dimensions (W x D x H)
911 x 790 x 1036 mm
Packaging data
Specification
Value
Package weight
83.1 kg
Packaging content
Specification
Value
Bundled software
Print drivers and installation software on CD-ROM (HP PCL 5e, HP PCL 6, HP Postscript Level 3 emulation)
Logistics data
Specification
Value
Pallet gross weight
83.1 kg
Products per pallet
1 pc(s)
Other features
Specification
Value
Mac compatibility
Yes
Minimum system requirements
Microsoft Windows 2000: 300 MHz processor with 64 MB RAM; Windows XP Home, Windows XP Professional: 233 MHz processor with 64 MB RAM; 180 MB free hard disk space; 1 GHz processor, 512 MB RAM [Windows Vista Ready, check user guide for minimum hard drive space], CD-ROM drive or Internet connection; de
CISPR 22: 1997/EN 55022: 1998 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995+A1, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B (USA), ICES-003, Issue 4, (Canada), GB9254-1998, EMC Directive 89/336/EEC with CE Marking (Europe) other EMC approvals as required by individual countries
Compatible operating systems
Microsoft Windows 2000, XP Home, XP Professional; Certified for Windows Vista; Mac OS 9; Mac OS X
Downloadable software
Microsoft Windows 98, Me, NT, 2000, XP, Server 2003, Macintosh OS 9, OS 10
Networking features
Via HP Jetdirect internal print servers for Fast Ethernet, Gigabit Ethernet; 802.11b wireless connectivity HP Jetdirect Fast Ethernet Embedded Print Server (10/100Base-TX)
Product dimensions when open (LxWxD)
139.7 cm (55")
Safety
Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-00), China (GB4943), Czech Republic (CSN-IEC 60950-IEC 60825-1), Estonia (EEI-EN60950-IEC 60825-1), EU (CE Mark-Low Voltage Directive 73/23/EEC), Germany (TÛV- EN60950-IEC 60825-1), Hungary (MEEI-
Size (imperial)
139.7 cm (55")
Standard input trays
3
Package dimensions (WxDxH)
911.9 x 789.9 x 721.4 mm
Print quality (black, draft quality)
600 DPI
Standard input capacity for transparencies
100
Recommended operating temperature range (T-T)
10 - 32.5 °C
I/O ports
1 IEEE 1284-B compliant parallel, 2 EIO slots
Custom media sizes
Multipurpose Tray 1: 98 x 191 to 312 x 470 mm; automatic two-sided printing unit, Tray 2, 3 and 8-bin mailbox: 148 x 210 to 297 x 432 mm. Optional Tray 4: 182 x 210 to 297 x 432 mm
Standard media sizes
A3, A4, A5, B4, B5, B6, Executive
Memory upgrade
0.512 GB
Print margin bottom (A4)
1 mm
Print margin left (A4)
1 mm
Print margin right (A4)
1 mm
Print margin top (A4)
1 mm
Typefaces
80 internal TrueType fonts scalable in HP PCL and HP Postscript Level 3 emulation; additional font solutions available via DIMMs
Media weights by paper path
Multipurpose Tray 1: 64 to 216 g/m2; automatic two-sided printing unit, Tray 2, 3, optional Tray 4: 64 to 200 g/m2
Standard output capacity for envelopes
60 sheets
Envelope feeder
No
Acoustic power emissions
7 B(A)
Acoustic pressure emissions
54 dB
Duplex print options
Automatic (optional)
Print speed (black, best quality, A4)
40 ppm
Acoustic power emissions (ready)
56 dB
Acoustic pressure emissions bystander (active, print, copy or scan)
Current drivers and software are available from the Internet. Depending on the configuration of Microsoft Windows driven computers, the installation program for the printer software automatically checks the computer for Internet access to obtain the latest software.
Duplex binding
Yes
Duplex supported media size
A3, A4, A4-rotated, A5, JIS B4, JIS B5, JIS B6, JIS executive
First page out (black&white, A4, ready)
8 s
First page out (black&white, letter, ready)
8 s
Maximum input capacity (tray 1)
100 sheets
Maximum paper trays
4
Media handling
Sheetfed
Media size (tray 2)
A4, B4, B5, A3, A5, custom; 148 x 210 to 297 x 432 mm
Enjoy fast, industry-leading networking with the HP Jetdirect Fast Ethernet internal print server Enjoy greater flexibility with optional automatic two-sided printing up to A3 size
