| Minimum system requirements | Microsoft Windows 2000, Server 2003: any Pentium II processor or higher, 64 MB RAM, 250 MB hard disk space, SVGA 800 x 600 with 16-bit colour display, Internet Explorer 5.5 or higher (full install), CD-ROM drive, USB port; (print driver only). Microsoft Windows XP-32 Home, XP-32 Professional: any Pe |
|---|
| Printer management | Toolbox (recommended install) or SNP (express install) |
|---|
| Power requirements | Input voltage 115 to 127 VAC (+/- 10%), 60 Hz (+/- 2 Hz), 12 A; 220 to 240 VAC (+/- 10%), 50 Hz (+/- 2 Hz), 6 A |
|---|
| Electromagnetic compatibility | CISPR 22: 2005/EN 55022: 2006 Class B, EN 61000-3-2: 2000+A2, EN 61000-3-3: 1995+A1, EN 55024: 1998+A1+A2, FCC Title 47 CFR, Part 15 Class B (USA), ICES-003, Issue 4, (Canada), GB9254-1998, EMC Directive 2004/108/EC with CE Marking (Europe), other EMC approvals as required by individual countries |
|---|
| Compatible operating systems | Microsoft Windows 2000, XP Home, XP Professional, Server 2003, XP Media Center, XP Professional x64; Windows Vista; Mac OS X v10.2.8, v10.3, v10.4 or higher |
|---|
| Downloadable software | Universal Print Driver for Windows, Windows CD image, Mac CD Image, Web JetAdmin, Easy Printer Care, Basic Color Match, Smart Web Printing In-House Marketing, Unix/Linux driver, Enterprise installer utility, Plug and Play bundles |
|---|
| Networking features | Via On-board internal networking 10/100Base-TX with RJ-45 connector |
|---|
| Product dimensions when open (LxWxD) | 40.4 cm (15.9") |
|---|
| Safety | IEC 60950-1 (International), EN 60950-1+A11 (EU), IEC 60825-1+A1+A2, UL/cUL Listed (US/Canada), GS License (Europe), EN 60825-1+A1+A2 (Class 1 Laser/LED Device) GB4943-2001, Low Voltage Directive 2006/95/EC with CE Marking (Europe); other safety approvals as required by individual countries |
|---|
| Size (imperial) | 40.4 cm (15.9") |
|---|
| Standard input trays | 2 |
|---|
| Package dimensions (WxDxH) | 600 x 500 x 479 mm |
|---|
| Print quality (black, normal quality) | 600 DPI |
|---|
| Recommended operating temperature range (T-T) | 15 - 27 °C |
|---|
| I/O ports | 1 USB; 1 Ethernet |
|---|
| Custom media sizes | Tray 1: 76 x 127 to 216 x 356 mm; Tray 2 and optional Tray 3: 100 x 148 to 216 x 356 mm |
|---|
| Standard media sizes | Tray 1: A4, A5, A6, B5 (JIS), 10 x 15 cm, 16K, envelopes (ISO DL, ISO C5, ISO B5), post cards (Standard #10, JIS Single, JIS Double); Tray 2 and optional Tray 3: A4, A5, A6, B5 (JIS), 10 x 15 cm, 16K, envelopes (ISO DL, ISO C5, ISO B5), post cards (JIS Single, JIS Double) |
|---|
| Print margin bottom (A4) | 4.23 mm |
|---|
| Print margin left (A4) | 4.23 mm |
|---|
| Print margin right (A4) | 4.23 mm |
|---|
| Print margin top (A4) | 4.23 mm |
|---|
| Typefaces | 84 scalable TrueType fonts |
|---|
| Media weights by paper path | Tray 1: 60 to 176 g/m² (up to 220 g/m² with HP laser glossy photo papers); tray 2, optional tray 3: 60 to 163 g/m² (up to 176 g/m² with postcards, up to 220 g/m² with HP laser glossy photo papers) |
|---|
| Recommended media weight | 60 - 163 g/m² |
|---|
| Standard output capacity for envelopes | 20 sheets |
|---|
| Envelope feeder | No |
|---|
| Acoustic power emissions | 6.6 B(A) (printing at 20 ppm), 3.1 B(A) (ready) |
|---|
| Print quality (colour, best quality) | 600 DPI |
|---|
| Duplex print options | Manual (driver support provided) |
|---|
| Print speed (colour, best quality, A4) | 20 ppm |
|---|
| Print speed (black, best quality, A4) | 20 ppm |
|---|
| Paper handling | 50-sheet multi-purpose tray, 250-sheet input tray, optional 2nd 250-sheet input tray, manual two-sided printing |
|---|
| Acoustic power emissions (ready) | 31 dB |
|---|
| Acoustic pressure emissions bystander (active, print, copy or scan) | 53 dB(A) |
|---|
| Acoustic pressure emissions bystander (ready) | Inaudible |
|---|
| Automatic paper sensor | No |
|---|
| Control panel | Backlit, 2-line, 16-character front panel display, 5 buttons (Cancel job, Left arrow, Right arrow, Select, Back); 2 LEDs (Attention, Ready) |
|---|
| Driver updates | http:///support/LJCP2020series |
|---|
| Duplex binding | No |
|---|
| Duplex supported media size | A4 |
|---|
| First page out (black&white, A4, ready) | 17.8 s |
|---|
| First page out (black&white, letter, ready) | 17.2 s |
|---|
| First page out (black&white, letter, sleep) | 17.6 s |
|---|
| Maximum paper trays | 3 |
|---|
| Media handling | Sheetfed |
|---|
| Media size (tray 2) | A4, A5, A6, B5 (JIS), 10 x 15 cm, 16K, envelopes (ISO DL, ISO C5, ISO B5), post cards (JIS Single, JIS Double), 100 x 148 to 216 x 356 mm |
|---|
| Media sizes supported (imperial) | Tray 1: letter, legal, executive, 8.5 x 13 in, 3 x 5 in, 4 x 6 in, 5 x 8 in, envelopes (No 10, Monarch); tray 2, optional tray 3: letter, legal, executive, 8.5 x 13 in, 4 x 6 in, 5 x 8 in, envelopes (No 10, Monarch) |
|---|
| Media type and capacity (tray 2) | sheets: 250, envelopes: 10 |
|---|
| Media weight (tray 2) | 60 to 163 g/m² (up to 176 g/m² with postcards, up to 220 g/m² with HP Color Laser Glossy Photo papers) |
|---|
| Media weight (tray 3) | 60 to 163 g/m² (up to 176 g/m² with postcards, up to 220 g/m² with HP Color Laser Glossy Photo papers) |
|---|
| Operating altitude (imperial) | 9000 ft |
|---|
| Package dimensions (W x D x H) | 599.9 x 499.9 x 478.8 mm (23.6 x 19.7 x 18.9") |
|---|
| Package weight (imperial) | 26.3 kg (58 lbs) |
|---|
| Pallet dimensions (W x D x H) (imperial) | 1198.9 x 1000.8 x 2545.1 mm (47.2 x 39.4 x 100.2") |
|---|
| Pallet weight (imperial) | 549.5 kg (1211.5 lbs) |
|---|
| Paper handling optional/input | Optional 2nd 250-sheet paper tray |
|---|
| Paper handling standard/input | 50-sheet multi-purpose tray, 250-sheet input tray |
|---|
| Paper handling standard/output | 150-sheet face-down output bin |
|---|
| Power consumption (active) | 445 W |
|---|
| Print quality (black, best quality) | 600 x 600 DPI |
|---|
| Print speed (black, best quality, letter) | < 21 |
|---|
| Print speed (colour, best quality, letter) | < 21 |
|---|
| Security management description | Password-protected network embedded web server, color lockout |
|---|
| Standard output capacity for transparencies | 50 sheets |
|---|
| SureSupply connection type | Direct and Network |
|---|
| SureSupply supported | Yes |
|---|
| Typical electricity consumption (TEC) number | 1.937 kWh/Week |
|---|
| Upgrade type | Memory upgradeable to 384 MB, optional 250-sheet tray, one additional tray may be added |
|---|
| Weight (imperial) | 50.0 lb |
|---|
