Minimum size 76 x 127 mm, maximum size 306 x 470 mm (maximum printable area 297 x 460 mm).
Media types supported
Paper (plain, light, intermediate, heavy, extra heavy, glossy, heavy glossy, high gloss images, tough, recycle), envelopes, transparencies, labels, cardstock
Media weight (tray 1)
Up to 200 g/m²
Network
Specification
Value
Network ready
Yes
Supported network protocols (IPv4)
Via HP Jetdirect print servers: TCP/IP, IPX/SPX, AppleTalk, Apple Rendezvous compatible, DLC/LLC, Auto-IP, IP Direct Mode, NDS, Bindery, NCP, NDPS, iPrint, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP v 1 and v 2c, HTTP; may require software from the NOS vendor or third-party vendor: LPD, FTP Printing,
Performance
Specification
Value
Internal memory
160 MB
Maximum internal memory
544 MB
Built-in processor
Yes
Processor model
MIPS RISC
Processor frequency
533 MHz
Power
Specification
Value
Power consumption (PowerSave)
24 W
Power consumption (off)
0.3 W
System requirements
Specification
Value
Minimum system requirements for Macintosh
Mac OS X v 10.2, v 10.3, v 10.4, v 10.5; 4 MB RAM and 160 MB free hard disk space; AppleTalk, Bonjour or USB connectivity solution
Operational conditions
Specification
Value
Operating temperature (T-T)
15 - 27 °C
Storage temperature (T-T)
0 - 35 °C
Operating relative humidity (H-H)
10 - 70%
Storage relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
63 - 77 °F
Weight & dimensions
Specification
Value
Weight
60 kg
Dimensions (WxDxH)
577 x 704 x 640 mm
Maximum dimensions (W x D x H)
577 x 1550 x 640 mm
Pallet dimensions (W x D x H)
1010 x 780 x 822 mm
Packaging data
Specification
Value
Package weight
85 kg
Packaging content
Specification
Value
Bundled software
Print drivers and installation software on CD-ROM (HP PCL 5c, HP PCL 6, HP Postscript Level 3 Emulation)
Logistics data
Specification
Value
Pallet gross weight
95 kg
Products per pallet
1 pc(s)
Other features
Specification
Value
Power supply type
110~220V
Minimum system requirements
Microsoft Windows 2000: 300 MHz Processor with 64 MB of RAM; Windows XP: 233 MHz Processor with 64 MB of RAM; 180 MB free hard disk space for Windows, 1 GHz processor, 512 MB RAM (Windows Vista Ready, check user guide for minimum hard drive space), 160 MB for Mac; Mac OS 9.0, 9.04, 9.1, 9.2, 10.1; C
Printer management
HP Web Jetadmin, HP Embedded Web Server, HP eToolbox
Power requirements
Input voltage 100 to 240 VAC (- 10/+ 6%), 50/60 Hz (+/-2 Hz)
Electromagnetic compatibility
CISPR 22: 1997/EN 55022: 1998 Class B, EN 61000-3-2:2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE-Marking accordingly
Compatible operating systems
Microsoft Windows 2000, XP Home, XP Professional, Windows Vista Ready, Windows Server 2003 (32/64 bit); Mac OS 9 or higher
Downloadable software
Microsoft Windows 2000, XP (32-bit and 64-bit drivers), Server 2003 (32-bit and 64-bit drivers); Apple Macintosh OS 9 and later, Mac OS X v.10.1 and later
Networking features
HP Jetdirect 620n Fast Ethernet Print Server Via HP Jetdirect print servers
One IEEE 1284-C compliant bidirectional parallel, one USB (compatible with USB 1.1 specifications), one jetlink, one 10/100Base- TX network port, two EIO slots
Custom media sizes
Tray 1: 76.2 x 127 to 216 x 356 mm; Tray 2, optional Tray 3 and Tray 4: 182 x 210 to 216 x 356 mm
Standard media sizes
A3, A4, A5, B4-JIS, B5-JIS
Memory upgrade
0.544 GB
Print margin bottom (A4)
5 mm
Print margin left (A4)
5 mm
Print margin right (A4)
5 mm
Print margin top (A4)
5 mm
Typefaces
80 internal scalable fonts available to HP PCL and HP Postscript Level 3 Emulation
Media weights by paper path
Tray 1: up to 200 g/m²; Tray 2, 3, 4, 5: up to 120 g/m²
Acoustic pressure emissions bystander (active, print, copy or scan)
49 dB(A)
Control panel
LCD backlit panel display with up to 4 lines of text and animated printer graphics, 3 LED status lights. "Cancel job", "Pause/Resume", "Help" buttons
Driver updates
Latest drivers for all supported operating systems available at http:///support/clj5550. If no access to the Internet, see support flyer that came in printer box.
Duplex binding
Yes
Duplex supported media size
A4, A4-rotated, A3, B4-JIS, B5-JIS
First page out (black&white, A4, ready)
16 s
First page out (black&white, letter, ready)
16 s
First page out (black&white, letter, sleep)
41 s
Maximum paper trays
5
Media handling
Sheetfed
Media size (tray 2)
A4, A3, A5, B4-JIS, B5-JIS
Media sizes supported (imperial)
Letter, legal, statement, executive, 11 x 17 in, ledger, envelopes (No. 10, Monarch)
Media type and capacity (tray 2)
sheets: 500
Media weight (tray 2)
Up to 120 g/m²
Media weight (tray 3)
Up to 120 g/m²
Memory technology
Memory Enhancement technology (MEt)
Operating altitude (imperial)
10000 ft
Package dimensions (W x D x H)
995.7 x 767.1 x 823 mm (39.2 x 30.2 x 32.4")
Package weight (imperial)
84.8 kg (187 lbs)
Pallet dimensions (W x D x H) (imperial)
1010.9 x 779.8 x 823 mm (39.8 x 30.7 x 32.4")
Pallet weight (imperial)
94.8 kg (208.9 lbs)
Paper handling optional/input
Tray 3: 500-sheet paper tray; Tray 4,5: 2 x 500-sheet paper trays; printer stand
