Letter, letter-R, legal, executive, tabloid (11 x 17 in), ledger, 16K, 8K, A3, A4, A4-R, A5, envelope (No. 10, DL, C5, B5, Monarch), B4-JIS, B5-JIS, executive-JIS, double postcard-JIS, 12 x 18 in, 8.5 x 13 in, A6, B6, RA3, statement, 76.2 x 98 to 306 x 470 mm
Media types supported
Paper (extra heavy, glossy, heavy, heavy glossy, high gloss images, intermediate, light, plain, recycle, tough), envelopes, labels, cardstock, transparencies
Media weight (tray 1)
200 g/m²
Network
Specification
Value
Network ready
Yes
Supported network protocols (IPv4)
TCP/IP, IPX/SPX, AppleTalk, Apple Rendezvous, DLC/LLC, Auto-IP, IP Direct Mode, NDS, Bindery, NCP, NDPS, iPrint, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP v1 & v2c, HTTP; LPD, FTP Printing, IPP
Performance
Specification
Value
Internal memory
288 MB
Maximum internal memory
544 MB
Internal storage capacity
20 GB
Storage media
HDD
Built-in processor
Yes
Processor model
MIPS RISC
Processor frequency
533 MHz
Power
Specification
Value
Power consumption (printing)
632 W
Power consumption (PowerSave)
28 W
Power consumption (off)
0.3 W
System requirements
Specification
Value
Minimum system requirements for Macintosh
Mac OS 9.0, 9.04, 9.1, 9.2, 10.1: 4 MB RAM & 160 MB HD
Operational conditions
Specification
Value
Operating temperature (T-T)
15 - 27 °C
Storage temperature (T-T)
0 - 35 °C
Operating relative humidity (H-H)
10 - 70%
Storage relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
63 - 77 °F
Weight & dimensions
Specification
Value
Weight
136 kg
Dimensions (WxDxH)
630 x 718 x 1097 mm
Maximum dimensions (W x D x H)
630 x 1550 x 1097 mm
Pallet dimensions (W x D x H)
1010 x 780 x 1359 mm
Packaging data
Specification
Value
Package weight
168 kg
Packaging content
Specification
Value
Bundled software
HP PCL 5c, HP PCL 6, HP Postscript Lvl 3
Logistics data
Specification
Value
Pallet gross weight
168 kg
Layers per pallet
5 pc(s)
Products per pallet
1 pc(s)
Other features
Specification
Value
Power supply type
110~220V
Mac compatibility
Yes
Minimum system requirements
Microsoft Windows 7 ready. For more information go to http:///go/windows7. Some features may not be available. Windows Vista: 1 GHz processor, 512 MB RAM (check User’s Guide for minimum hard disk space); Windows 2000: 300 MHz processor, 64 MB RAM; Windows XP: 233 MHz processor, 64 MB RAM; for all sy
Printer management
HP Web Jetadmin, HP Embedded Web Server, HP eToolbox
Power requirements
100 - 240 VAC (- 10/+ 6%), 50/60 Hz (+/-2 Hz)
Electromagnetic compatibility
CISPR 22: 1997/EN 55022: 1998 Class B, EN 61000-3-2:2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE-Marking accordingly
Compatible operating systems
Windows Vista; UNIX, Linux, Novell NetWare 5.1 +, OS/2 Microsoft Windows 2000, XP Home, XP Professional, Windows Vista Ready, Windows Server 2003 (32/64 bit); Mac OS 9 +
Downloadable software
Microsoft Windows 2000, XP (32-bit and 64-bit drivers), Server 2003 (32-bit and 64-bit drivers); Apple Macintosh OS 9 and later, Mac OS X v.10.1 and later
Networking features
Fast Ethernet
Product dimensions when open (LxWxD)
63 cm (24.8")
Safety
Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-00), China (GB4943), Czech Republic (CSN-IEC 60950-IEC 60825-1), Estonia (EEI-EN60950-IEC 60825-1), EU (CE Mark-Low Voltage Directive 73/23/EEC), Germany (TUV- EN60950-IEC 60825-1), Hungary (MEEI-
Size (imperial)
63 cm (24.8")
Standard input trays
5
Package dimensions (WxDxH)
979 x 797 x 1359 mm
Additional paper trays
500-sheet input tray 4 and feeder
Print quality (black, draft quality)
600 DPI
Print quality (black, normal quality)
600 DPI
Recommended humidity operating range
30 - 70%
Recommended operating temperature range (T-T)
15 - 25 °C
I/O ports
1 x IEEE 1284-C, 1 x USB, 1 x 10/100Base- TX, 1 x EIO
Input capacity for envelopes (primary tray)
20 sheets
Custom media sizes
Tray 1: 76 x 127 to 306 x 470 mm; automatic two-sided printing, Tray 2, 3, 4, 5: 148 x 210 to 297 x 431.8 mm Tray 1: 3 x 5 to 12.05 x 18.5 in; automatic two-sided printing, Trays 2, 3, 4, 5: 5.8 x 8.3 to 11.7 x 17 in
Memory upgrade
0.544 GB
Print margin bottom (A4)
5 mm
Print margin left (A4)
5 mm
Print margin right (A4)
5 mm
Print margin top (A4)
5 mm
Typefaces
80 internal TrueType fonts scalable in HP PCL, 92 internal scalable fonts in HP Postscript Level 3 emulation (Euro symbol built-in); additional font solutions available via third-party flash memory cards
Recommended media weight
Tray 1: 60 - 200; Tray 2, 3, 4, 5: 60 - 120
Standard output capacity for envelopes
40 sheets
Envelope feeder
No
Acoustic power emissions
LwAd: 6.6 B(A)
Acoustic pressure emissions
49 dB
Print quality (colour, best quality)
600 DPI
Duplex print options
Automatic (standard)
Duty cycle letter size (maximum)
120000 pages per month
Print speed (colour, best quality, A4)
28 ppm
Print speed (black, best quality, A4)
28 ppm
Colour printing technology
HP ImageREt 3600
Paper handling
100
Acoustic pressure emissions bystander (active, print, copy or scan)
49 dB(A)
Control panel
LCD
Driver updates
OS/2, UNIX, Linux; basic printing support for DOS; current drivers and software are available from the Internet at /support/clj5550
Duplex binding
Yes
Duplex supported media size
A3, A4, A5, B4-JIS, B5-JIS
First page out (black&white, A4, ready)
16 s
First page out (black&white, letter, ready)
16 s
First page out (black&white, letter, sleep)
41 s
Maximum paper trays
5
Media handling
Sheetfed
Media size (tray 2)
A4, A3, A5, B4-JIS, B5-JIS
Media sizes supported (imperial)
Letter, legal, statement, executive, 11 x 17 in, ledger, envelopes (No. 10, Monarch)
Media type and capacity (tray 2)
500
Media weight (tray 2)
120 g/m²
Media weight (tray 3)
120 g/m²
Memory technology
Memory Enhancement technology (MEt)
Operating altitude (imperial)
10000 ft
Package dimensions (W x D x H)
977.9 x 797.6 x 1358.9 mm (38.5 x 31.4 x 53.5")
Package weight (imperial)
167.6 kg (369.6 lbs)
Pallet dimensions (W x D x H) (imperial)
1010.9 x 779.8 x 1358.9 mm (39.8 x 30.7 x 53.5")
Pallet weight (imperial)
167.6 kg (369.6 lbs)
Paper handling optional/input
Tray 3: 500-sheet paper tray; Tray 4,5: 2 x 500-sheet paper trays; printer stand
1 year on-site warranty. Optional HP Care Pack services available.
Standard output capacity for transparencies
250 sheets
Technical features
Empower your business with wide-format colour laser printing. Proven performer with up to 28 ppm, 16 second first page out from "Ready" and up to 288 MB RAM. Simplify printer management with HP Embedded Web Server and HP Web Jetadmin. Demand versatility with expanded media support for a range of opt
UNSPSC-code
43212105
Upgrade type
Color tables, formatter firmware, software drivers
Weight (imperial)
141.5 kg (312 lbs)
Wireless option type
Optional, enabled with purchase of a hardware accessory
