AcuLaser C3800N
Model AcuLaser C3800NPart no. C11C648001BUEAN 8715946462752
79 specifications
- ProcessorPowerPC 750FL
- Memory128 MB
- Weight25.8 kg
- ColourYes
- Maximum duty cycle60000 pages per month
- Total number of input trays1
Overview
- Processor
- PowerPC 750FL
- Memory
- 128 MB
- Weight
- 25.8 kg
- Colour
- Yes
- Maximum duty cycle
- 60000 pages per month
- Total number of input trays
- 1
- Brand
- Epson
- Category
- Laser Printer
- Model
- AcuLaser C3800N
- Part numbers
- C11C648001BU, C11C648001BZ, C11C648001JA, C11C648001BE
- EAN / UPC
- 8715946462752, 3540260039084, 8715946328287, 8715946328294 +1 more
- Also known as
- Epson AcuLaser C3800N
Specifications
79 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Print technology | Laser |
| Duplex printing | No |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 25 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 20 ppm |
| Warm-up time | 30 s |
| Time to first page (black, normal) | 15 s |
| Time to first page (colour, normal) | 15 s |
| Economical printing | Yes |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 60000 pages per month |
| Number of print cartridges | 4 |
| Page description languages | PDF 1.3 |
| Printer fonts | Barcode, Bitmap, PCL, PostScript |
| Number of PCL fonts | 181 |
| Number of PostScript fonts | 136 |
| Number of bitmap fonts | 15 |
| Country of origin | China |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 150 sheets |
| Total output capacity | 250 sheets |
| Maximum input capacity | 1250 sheets |
| Maximum output capacity | 250 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Maximum print size | 216 x 356 mm |
| ISO A-series sizes (A0...A9) | A4 |
| ISO B-series sizes (B0...B9) | B5 |
| Non-ISO print media sizes | Executive, Legal, Letter |
| JIS B-series sizes (B0...B9) | B5 |
| Paper tray media weight | 60 - 216 g/m² |
| Media weight (tray 1) | 60-216 gsm |
Network
| Specification | Value |
|---|---|
| Network ready | Yes |
| Supported network protocols (IPv4) | TCP/IP: LPR, FTP, IPP, PORT2501, PORT9100; NetBIOS over TCP/IP, NetBIOS over NetBEUI; Netware: Standby, NDS Print Server, Bindery Print Server, Remote Printer; AppleTalk |
| Management protocols | TCP/IP: SNMP, HTTP, TELNET, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SNTP, SSDP, SLP; Microsoft Network: AutoIP, SSDP; NetBEUI: SNMP, SSDP; NetWare, AppleTalk: SNMP, EMPC |
Performance
| Specification | Value |
|---|---|
| Internal memory | 128 MB |
| Maximum internal memory | 1024 MB |
| Built-in processor | Yes |
| Processor model | PowerPC 750FL |
| Processor frequency | 600 MHz |
| Sound pressure level (printing) | 51 dB |
| Sound power level (standby) | 30 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 78 W |
| Power consumption (PowerSave) | 17 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 32 °C |
| Storage temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 15 - 80% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 420 mm |
| Depth | 501 mm |
| Height | 508 mm |
| Weight | 25.8 kg |
| Dimensions (WxDxH) | 420 x 501 x 508 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 580 mm |
| Package depth | 750 mm |
| Package height | 630 mm |
| Package weight | 34.6 kg |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross width | 120 cm |
| Pallet gross height | 100 cm |
| Products per pallet layer | 2 pc(s) |
| Products per pallet | 6 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.04 m |
| Products per pallet layer (UK) | 2 pc(s) |
| Products per pallet (UK) | 6 pc(s) |
Other features
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Power requirements | 220V - 240V ±10% / 50Hz / 60Hz ± 3Hz / 4.0 A |
| Electromagnetic compatibility | EMC Directive 89/336/EEC EN 55022 Class B, EN 55024, EN 61000-3-2; EN 61000-3-3, JBMIA |
| Compatible operating systems | Mac OS 10.3+, Windows 2000, Windows XP |
| Emulations | PCL5c, PCL6, ESC/P2, ESC/Page, ESC/Page-Colour, PostScript 3, PDF 1.3, FX, I239X |
| Fonts included | Yes |
| Networking features | 10/100 Base Tx |
| Quantity per pack | 1 pc(s) |
| Safety | 73/23/EEC EN 60950, EN60825-1, OSHA, TSCA, EINECS |
| Standard input trays | 1 x 150 + 1 x 550 |
| Non-operating relative humidity (non-condensing) | 15 - 85% |
| Standard media sizes | GLT, HLT, GLG, C5, DL |
| Power consumption (active) | 361 W |
| Print speed | 25 Pages/min Monochrome single-sided, 20 pages/min colour single-sided |
