X C1946P
Model X C1946PPart no. 5728C004
59 specifications
- Memory2000 MB
- Storage32 GB
- Weight45 kg
- ColourYes
- Maximum duty cycle165000 pages per month
- Total number of input trays1
Overview
- Memory
- 2000 MB
- Storage
- 32 GB
- Weight
- 45 kg
- Colour
- Yes
- Maximum duty cycle
- 165000 pages per month
- Total number of input trays
- 1
- Brand
- Canon
- Category
- Laser Printer
- Model
- X C1946P
- Part number
- 5728C004
- Also known as
- Canon i-SENSYS X C1946P Colour 1200 x 1200 DPI A3 Wi-Fi
Specifications
59 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Print technology | Laser |
| Duplex printing | Yes |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A3) | 46 ppm |
| Warm-up time | 34 s |
| Time to first page (black, normal) | 7.54 s |
| Time to first page (colour, normal) | 8.35 s |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 165000 pages per month |
| Recommended duty cycle | 2500 - 7500 pages per month |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Page description languages | PCL 5c, PCL 6, PostScript 3, UFRII |
| Printer fonts | Barcode, Bitmap, PCL, PostScript |
| Bitmap fonts | Roman |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 650 sheets |
| Total output capacity | 200 sheets |
| Paper tray 1 input capacity | 550 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 100 sheets |
| Maximum input capacity | 2850 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Paper tray media types | Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Postcard, Rough paper |
| ISO A-series sizes (A0...A9) | A3, A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B4, B5 |
Ports & interfaces
| Specification | Value |
|---|---|
| Direct printing | Yes |
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, IPSec, SSL/TLS, TKIP, WPA-EAP, WPA-PSK, WPA2-PSK |
| Management protocols | SNMPv1, SNMPv3 |
| Mobile printing technologies | Apple AirPrint, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 2000 MB |
| Internal storage capacity | 32 GB |
| Storage media | eMMC |
| Built-in processor | Yes |
| Sound pressure level (printing) | 52 dB |
| Sound pressure level (duplex printing) | 51 dB |
| Sound power level (printing) | 71.8 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | Black, White |
| Built-in display | Yes |
| Display | LCD |
| Control type | Buttons |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 970 W |
| Power consumption (max) | 1500 W |
| Power consumption (standby) | 50 W |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50/60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 8.1 |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 30 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 556 mm |
| Depth | 608 mm |
| Height | 403 mm |
| Weight | 45 kg |
