X C1538P II
Model X C1538P IIPart no. 6173C002EAN 4549292221503
69 specifications
- Memory2000 MB
- Storage32 GB
- Weight25 kg
- ColourYes
- Maximum duty cycle50000 pages per month
- Total number of input trays1
Overview
- Memory
- 2000 MB
- Storage
- 32 GB
- Weight
- 25 kg
- Colour
- Yes
- Maximum duty cycle
- 50000 pages per month
- Total number of input trays
- 1
- Brand
- Canon
- Category
- Laser Printer
- Model
- X C1538P II
- Part number
- 6173C002
- EAN / UPC
- 4549292221503
- Also known as
- Canon i-SENSYS X C1538P II Colour 1200 x 1200 DPI A4 Wi-Fi
Specifications
69 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Print technology | Laser |
| Duplex printing | Yes |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 38 ppm |
| Duplex print speed (colour, normal quality, A4/US Letter) | 38 ppm |
| Warm-up time | 2 s |
| Time to first page (black, normal) | 5.3 s |
| Time to first page (colour, normal) | 6.3 s |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 50000 pages per month |
| Recommended duty cycle | 1500 - 5000 pages per month |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Number of print cartridges | 4 |
| Page description languages | PCL 5, PCL 6, PostScript 3, UFRII |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 650 sheets |
| Total output capacity | 200 sheets |
| Paper tray 1 input capacity | 550 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 100 sheets |
| Maximum number of input trays | 3 |
| Maximum input capacity | 2300 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Card stock, Coated paper, Envelopes, Heavy paper, Plain paper, Recycled paper, Thin paper |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5 |
| Non-ISO print media sizes | Executive, Letter, Oficio, Statement |
| Envelopes sizes | C5, Com-10, DL, Monarch |
| Custom media width | 101.6 - 216 mm |
| Custom media length | 148 - 297 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Direct printing | Yes |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, IPSec, SSL/TLS, TKIP, WPA-EAP, WPA-PSK, WPA2-PSK |
| Supported network protocols (IPv4) | TCP/IP (LPD/Port9100/IPP/IPPS/FTP/WSD) |
| Supported network protocols (IPv6) | TCP/IP (LPD/Port9100/IPP/IPPS/FTP/WSD) |
| Management protocols | SNMPv1, SNMPv3 (IPv4,IPv6) |
| Mobile printing technologies | Apple AirPrint, Canon PRINT Business |
Performance
| Specification | Value |
|---|---|
| Internal memory | 2000 MB |
| Internal storage capacity | 32 GB |
| Storage media | eMMC |
| Built-in processor | Yes |
| Sound pressure level (printing) | 50 dB |
| Sound pressure level (duplex printing) | 52 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | Black, White |
| Built-in display | Yes |
| Display | LCD |
| Control type | Buttons |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 640 W |
| Power consumption (max) | 1500 W |
| Power consumption (standby) | 30.1 W |
| Energy Star Typical Electricity Consumption (TEC) | 0.39 kWh/week |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50/60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 8.1 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | Android, iOS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 30 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 458 mm |
| Depth | 464 mm |
| Height | 388 mm |
| Weight | 25 kg |
