imageCLASS LBP236dw
600 x 600 DPI Wi-Fi
Model LBP236dwPart no. 5162C005EAN 8714574670218
45 specifications
- Memory1024 MB
- Weight8.8 kg
- ColourWhite
- Print technologyLaser
- Maximum duty cycle10000 pages per month
- Total input capacity500 sheets
Overview
- Memory
- 1024 MB
- Weight
- 8.8 kg
- Colour
- White
- Print technology
- Laser
- Maximum duty cycle
- 10000 pages per month
- Total input capacity
- 500 sheets
- Brand
- Canon
- Category
- Laser Printer
- Model
- LBP236dw
- Part numbers
- 5162C005, 5162C006, 5162C013
- EAN / UPC
- 8714574670218, 013803344097, 4549292186550
- Also known as
- Canon imageCLASS LBP236dw 600 x 600 DPI Wi-Fi
Specifications
45 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Laser |
| Maximum resolution | 600 x 600 DPI |
| Print speed (black, normal quality, A4/US Letter) | 40 ppm |
| Warm-up time | 14 s |
| Time to first page (black, normal) | 5.4 s |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 10000 pages per month |
| Printing colours | Black |
| Number of print cartridges | 1 |
| Page description languages | PCL 5, PCL 6, PostScript 3, UFRII |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 500 sheets |
| Total output capacity | 250 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 100 sheets |
| Maximum input capacity | 900 sheets |
Ports & interfaces
| Specification | Value |
|---|---|
| Direct printing | Yes |
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Network ready | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA2-AES, WPA2-PSK, WPA2-TKIP |
| Mobile printing technologies | Apple AirPrint, Canon PRINT Business, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 1024 MB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | White |
| Built-in display | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 1300 W |
| Power consumption (max) | 1300 W |
| Power consumption (standby) | 8.5 W |
| Power consumption (off) | 0.9 W |
| Energy Star Typical Electricity Consumption (TEC) | 0.33 kWh/week |
| AC input voltage | 120 - 127 V |
| AC input frequency | 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion |
| Server operating systems supported | Windows Server 2012, Windows Server 2016 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 30 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 401 mm |
| Depth | 373 mm |
| Height | 249 mm |
| Weight | 8.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 13 kg |
