HLL8360CDWT Colour
2400 x 600 DPI A4 Wi-Fi
Model HLL8360CDWTPart no. HL-L8360CDWTEAN 012502646433
84 specifications
- Display6.86 cm (2.7")
- Memory512 MB
- Weight28.4 kg
- ColourYes
- Maximum duty cycle60000 pages per month
- Total input capacity750 sheets
Overview
- Display
- 6.86 cm (2.7")
- Memory
- 512 MB
- Weight
- 28.4 kg
- Colour
- Yes
- Maximum duty cycle
- 60000 pages per month
- Total input capacity
- 750 sheets
- Brand
- Brother
- Category
- Laser Printer
- Model
- HLL8360CDWT
- Part number
- HL-L8360CDWT
- EAN / UPC
- 012502646433
- Also known as
- Brother HLL8360CDWT Colour 2400 x 600 DPI A4 Wi-Fi
Specifications
84 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Print technology | Laser |
| Duplex printing | Yes |
| Duplex printing mode | Auto |
| Maximum resolution | 2400 x 600 DPI |
| Print speed (black, normal quality, A4/US Letter) | 33 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 33 ppm |
| Time to first page (black, normal) | 15 s |
| Time to first page (colour, normal) | 15 s |
| Secure printing | Yes |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 60000 pages per month |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Number of print cartridges | 4 |
| Page description languages | BR-Script 3, PCL 5c, PCL 5e, PCL 6, PDF 1.7, XPS |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 750 sheets |
| Total output capacity | 150 sheets |
| Paper input type | Paper tray |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Letterhead, Plain paper, Recycled paper, Thin paper |
| Multi-purpose tray media types | Bond paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Envelopes sizes | C5, Com-10, DL |
| Paper tray media weight | 60 - 105 g/m² |
| Paper tray media weight (imperial) | 7.26 - 12.7 kg (16 - 28 lbs) |
| Multi-Purpose Tray media weight | 60 - 163 g/m² |
| Multi-Purpose Tray media weight (imperial) | 7.26 - 19.5 kg (16 - 43 lbs) |
| Duplex media weight | 60 - 105 g/m² |
| Duplex media weight (imperial) | 16 - 28 lbs |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Ethernet, NFC, Wireless LAN |
| Direct printing | Yes |
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi Direct | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Near Field Communication (NFC) | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
| Supported network protocols (IPv4) | Web Services, APIPA (Auto IP), ARP, BOOTP, CIFS Client, Custom Raw Port/Port 9100, DHCP, DNS Resolver, FTP Server, HTTP/HTTPS Server, ICMP, IPP/IPPS, LDAP, LLMNR Responder, LPR/LPD, mDNS, RARP, SMTP Client, SNMPv1/v2c/v3, SNTP Client, TELNET Server, TFTP Client and Server, WINS/NetBIOS Name Resoluti |
| Supported network protocols (IPv6) | Web Services, NDP, RA, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, IPP/IPPS, SMTP Client, FTP Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMPv6, SNTP Client, LDAP |
| Mobile printing technologies | Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
| Sound pressure level (printing) | 49 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | Black, White |
| Built-in display | Yes |
| Display | LCD |
| Colour display | Yes |
| Display diagonal | 6.86 cm (2.7") |
| Touchscreen | Yes |
| Control type | Touch |
| Certification | Cerner Certified, Citrix Ready |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 600 W |
| Power consumption (ready) | 75 W |
| Power consumption (off) | 0.02 W |
| Energy Star Typical Electricity Consumption (TEC) | 0.578 kWh/week |
| AC input voltage | 120 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 32 °C |
| Storage temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | EPEAT Silver, ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 441 mm |
| Depth | 495 mm |
| Height | 445 mm |
| Weight | 28.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Included cartridge capacity (black) | 3000 pages |
| Included cartridge capacity (CMY) | 1800 pages |
| Cables included | AC |
| Drivers included | Yes |
| Manual | Yes |
| Printer drum included | Yes |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Power LED | Yes |
| Quantity per pack | 1 pc(s) |
| Stand-by LED | Yes |
| Supported network protocols | SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), SNMP v3, Kerberos, IPSec, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model HL-L9310CDW · certified Aug 19, 2019 · United States, Taiwan, Canada
| Measurement | Value |
|---|---|
| Typical energy consumption | 30.16 kWh/year |
