HL-1223WE 2400 x 600 DPI A4 Wi-Fi
Model HL-1223WEPart no. HL-1223WEAP2EAN 4977766792080
62 specifications
- ProcessorARM Cortex
- Memory32 MB
- Weight4.6 kg
- ColourNo
- Printing coloursBlack
- Total input capacity150 sheets
Overview
- Processor
- ARM Cortex
- Memory
- 32 MB
- Weight
- 4.6 kg
- Colour
- No
- Printing colours
- Black
- Total input capacity
- 150 sheets
- Brand
- Brother
- Category
- Laser Printer
- Model
- HL-1223WE
- Part number
- HL-1223WEAP2
- EAN / UPC
- 4977766792080
- Also known as
- Brother HL-1223WE 2400 x 600 DPI A4 Wi-Fi
Specifications
62 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Print technology | LED |
| Duplex printing | No |
| Maximum resolution | 2400 x 600 DPI |
| Print resolution black | 2400 x 600 DPI |
| Print speed (black, normal quality, A4/US Letter) | 20 ppm |
| Warm-up time (from sleep mode) | 18 s |
| Time to first page (black, normal) | 10 s |
Features
| Specification | Value |
|---|---|
| Printing colours | Black |
| Number of print cartridges | 1 |
| Page description languages | GDI |
Input & output capacity
| Specification | Value |
|---|---|
| Total input capacity | 150 sheets |
| Total output capacity | 50 sheets |
| Paper input type | Paper tray |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Plain paper, Recycled paper |
| ISO A-series sizes (A0...A9) | A4, A5 |
| ISO B-series sizes (B0...B9) | B6 |
| Non-ISO print media sizes | Folio, Legal |
| Paper tray media weight | 65 - 105 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | No |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | 64-bit WEP, 128-bit WEP, SMTP-AUTH, WPA-PSK, WPA2-PSK |
| Supported network protocols (IPv4) | ARP, RARP, BOOTP, DHCP, APIPA(Auto IP),WINS/NetBIOSnameresolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, CustomRaw Port/Port9100, klient SMTP, IPP/IPPS, serwer FTP, SNMPv1/v2c/v3,serwer HTTP/HTTPS, TFTP, ICMP, Web Services |
| Supported network protocols (IPv6) | NDP, RA, DNS resolver,mDNS, LLMNR responder, LPR/LPD, CustomRaw Port/Port9100, IPP/IPPS, klient SMTP,serwer FTP, SNMPv1/v2c/v3,serwer HTTP/ HTTPS, TFTP, ICMPv6, klient SNTP, Web Services |
| Mobile printing technologies | Brother iPrint & Scan |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32 MB |
| Built-in processor | Yes |
| Processor family | ARM Cortex |
| Processor model | A9 |
| Processor frequency | 200 MHz |
| Sound pressure level (printing) | 51 dB |
Design
| Specification | Value |
|---|---|
| Market positioning | Home & office |
| Product colour | Black, White |
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power consumption (printing) | 380 W |
| Power consumption (ready) | 40 W |
| Power consumption (off) | 0.7 W |
| Energy Star Typical Electricity Consumption (TEC) | 700 kWh/week |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 340 mm |
| Depth | 238 mm |
| Height | 189 mm |
| Weight | 4.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 415 mm |
| Package depth | 303 mm |
| Package height | 324 mm |
| Package weight | 5.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Warranty card | Yes |
| Cables included | AC |
| Drivers included | Yes |
| Quick start guide | Yes |
| Software CD | Yes |
Other features
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
