T1A X1 TBLT 1 GEN M7-6Y75 1.20GHZ

Model X1 TBLT 1 GEN M7-6Y75 1.20GHZPart no. L-X1T-UK-P001

103 specifications Checked yesterday

Display30.5 cm (12")
Resolution2160 x 1440 pixels
ProcessorIntel® Core™ m7
Memory16 GB
Storage256 GB
GraphicsNot available

See all specifications

Overview

Display: 30.5 cm (12")
Resolution: 2160 x 1440 pixels
Processor: Intel® Core™ m7
Memory: 16 GB
Storage: 256 GB
Graphics: Not available

Brand: T1A
Category: Laptop
Model: X1 TBLT 1 GEN M7-6Y75 1.20GHZ
Part number: L-X1T-UK-P001
Also known as: T1A X1 TBLT 1 GEN M7-6Y75 1.20GHZ Intel® Core™ m7 Hybrid (2-in-1) 30.5 cm (12") Touchscreen 16 GB LPDDR3-SDRAM 256 GB SSD Wi-Fi 4 (802.11n) Windows 10 Pro Black

Specifications

103 specifications in 11 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Black
Form factor	Convertible (Detachable)

Display

Specification	Value
Display diagonal	30.5 cm (12")
Display resolution	2160 x 1440 pixels
Touchscreen	Yes

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ m7
Processor generation	Intel® Core™ m7-6xxx
Processor model	m7-6Y75
Processor cores	2
Processor threads	4
Processor boost frequency	3.1 GHz
Processor frequency	1.2 GHz
Processor cache	4 MB
Processor cache type	Smart Cache
Processor socket	BGA 1515
Processor lithography	14 nm
Processor operating modes	32-bit, 64-bit
Processor series	Intel Core m7-6Y series
Processor codename	Skylake
Bus type	OPI
Stepping	D1
Thermal Design Power (TDP)	4.5 W
Configurable TDP-up	7 W
Configurable TDP-down	3.5 W
Tjunction	100 °C
Maximum number of PCI Express lanes	10
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
PCI Express slots version	3.0

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	256 GB
Storage media	SSD
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.4
On-board graphics card ID	0x191E

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	No
Bluetooth	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0

Software

Specification	Value
Operating system installed	Windows 10 Pro

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	Yes
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	14 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	Yes
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	1.00
Intel Smart Response Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel Stable Image Platform Program (SIPP) version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Smart Cache	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	88199
Processor code	SR2EH
Processor package size	20 X 16.5 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Weight & dimensions

Specification	Value
Weight	1.07 kg
Width	297.5 mm
Depth	209.5 mm
Height	13 mm
