R522-Aura T6500 Amara
Model R522-Aura T6500 AmaraPart no. NP-R522-JS06DEEAN 8808993660568
101 specifications Checked today
- Display39.6 cm (15.6")
- Resolution1366 x 768 pixels
- ProcessorIntel® Core™2 Duo
- Memory4 GB
- Storage500 GB
- GraphicsAMD Radeon HD 4650
Overview
- Display
- 39.6 cm (15.6")
- Resolution
- 1366 x 768 pixels
- Processor
- Intel® Core™2 Duo
- Memory
- 4 GB
- Storage
- 500 GB
- Graphics
- AMD Radeon HD 4650
- Brand
- Samsung
- Category
- Laptop
- Model
- R522-Aura T6500 Amara
- Part number
- NP-R522-JS06DE
- EAN / UPC
- 8808993660568
- Also known as
- Samsung R R522-Aura T6500 Amara Intel® Core™2 Duo 39.6 cm (15.6") 4 GB DDR2-SDRAM 500 GB AMD Radeon HD 4650 Windows 7 Home Premium Black
Specifications
101 specifications in 19 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1366 x 768 pixels |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display brightness | 220 cd/m² |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™2 Duo |
| Processor model | T6500 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 2.1 GHz |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor front side bus | 800 MHz |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor codename | Penryn |
| Bus type | FSB |
| Stepping | R0 |
| Thermal Design Power (TDP) | 35 W |
| Tjunction | 105 °C |
| Number of Processing Die Transistors | 410 M |
| Processing Die size | 107 mm² |
| CPU multiplier (bus/core ratio) | 10.5 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 2 x 2 GB |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 4 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| HDD interface | SATA |
| HDD speed | 5400 RPM |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD, SDHC |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Radeon HD 4650 |
| Graphics card family | AMD |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC272 |
| Audio system | HD |
| Number of built-in speakers | 2 |
| Speaker power | 3 W |
Camera
| Specification | Value |
|---|---|
| Front camera resolution (numeric) | 1.3 MP |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
| Wireless technology | 802.11b/g/n |
| Bluetooth | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 0 |
| Firewire (IEEE 1394) ports | 0 |
| Headphone outputs | 1 |
| S/PDIF out port | No |
| Microphone in | Yes |
| Docking connector | No |
| ExpressCard slot | Yes |
| CardBus PCMCIA slots quantity | 0 |
| CardBus PCMCIA slot type | No |
| SmartCard slot | No |
| Modem (RJ-11) ports | 0 |
| TV-in port | No |
| TV-out | No |
| PS/2 ports quantity | 0 |
| Parallel ports quantity | 0 |
| Serial ports quantity | 0 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® PM45 Express |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad + Scroll zone |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Home Premium |
| Drivers included | Yes |
| Trial software | Microsoft Office 2007 |
| Bundled software | SAMSUNG Recovery Solution III Adobe Acrobat Reader |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Processor ARK ID | 39311 |
| Processor code | SLGF4 |
Battery
| Specification | Value |
|---|---|
| Number of battery cells | 6 |
| Battery life (max) | 5 h |
| Battery recharge time | 3 h |
Power
| Specification | Value |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| DC-in jack | Yes |
Security
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| HDD user password | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.55 kg |
| Width | 376 mm |
| Depth | 255.8 mm |
| Height | 31.3 mm |
| Height (front) | 3.13 cm |
| Height (rear) | 3.72 cm |
| Dimensions (WxDxH) | 376 x 255.8 x 31.3 mm |
Other features
| Specification | Value |
|---|---|
| Infrared data port | No |
| Internal modem | No |
| Supplied AC adapter type | AC |
