R NP-R505-FS02 RM-72
39.1 cm (15.4") 3 GB DDR2-SDRAM 320 GB AMD Radeon HD 3470 Hybrid X2 Windows Vista Home Premium Black
Model NP-R505-FS02Part no. NP-R505-FS02UKEAN 8808993013654
90 specifications Checked today
- Display39.1 cm (15.4")
- Resolution1280 x 800 pixels
- ProcessorRM-72
- Memory3 GB
- Storage320 GB
- GraphicsAMD Radeon HD 3470 Hybrid X2
Overview
- Display
- 39.1 cm (15.4")
- Resolution
- 1280 x 800 pixels
- Processor
- RM-72
- Memory
- 3 GB
- Storage
- 320 GB
- Graphics
- AMD Radeon HD 3470 Hybrid X2
- Brand
- Samsung
- Category
- Laptop
- Model
- NP-R505-FS02
- Part number
- NP-R505-FS02UK
- EAN / UPC
- 8808993013654
- Also known as
- Samsung R NP-R505-FS02 RM-72 39.1 cm (15.4") 3 GB DDR2-SDRAM 320 GB AMD Radeon HD 3470 Hybrid X2 Windows Vista Home Premium Black
Specifications
90 specifications in 20 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.1 cm (15.4") |
| Display resolution | 1280 x 800 pixels |
| Native aspect ratio | 16:10 |
| Display surface | Gloss |
| Display brightness | 220 cd/m² |
Processor
| Specification | Value |
|---|---|
| Processor model | RM-72 |
| Processor frequency | 2.1 GHz |
| Processor cache | 1 MB |
| Processor cache type | L2 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 3 GB |
| Internal memory type | DDR2-SDRAM |
| Memory clock speed | 800 MHz |
| Maximum internal memory | 4 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 320 GB |
| HDD interface | SATA |
| HDD speed | 5400 RPM |
| Optical drive type | DVD Super Multi |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD, SDHC |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Radeon HD 3470 Hybrid X2 |
| Discrete graphics card memory | 0.512 GB |
| On-board graphics card model | Not available |
| Maximum graphics card memory | 0.768 GB |
Audio
| Specification | Value |
|---|---|
| Audio system | Intel HDA |
| Number of built-in speakers | 2 |
| Speaker power | 4 W |
Camera
| Specification | Value |
|---|---|
| Front camera resolution (numeric) | 1.3 MP |
Optical drive
| Specification | Value |
|---|---|
| CD-R read speed | 24x |
| CD-R write speed | 24x |
| CD-RW read speed | 24x |
| CD-RW write speed | 24x |
| DVD-R read speed | 8x |
| DVD-R write speed | 8x |
| DVD-R Double Layer read speed | 4x |
| DVD-R Double Layer write speed | 4x |
| DVD-RW read speed | 6x |
| DVD-RW write speed | 6x |
| DVD+R read speed | 8x |
| DVD+R write speed | 8x |
| DVD+R Double Layer read speed | 4x |
| DVD+R Double Layer write speed | 4x |
| DVD+RW read speed | 6x |
| DVD+RW write speed | 6x |
| DVD-RAM read speed | 5x |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit LAN |
| Wireless technology | 802.11b/g |
| Bluetooth | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 1 |
| Firewire (IEEE 1394) ports | 0 |
| Headphone outputs | 1 |
| S/PDIF out port | No |
| Microphone in | Yes |
| Docking connector | No |
| ExpressCard slot | Yes |
| CardBus PCMCIA slots quantity | 0 |
| CardBus PCMCIA slot type | No |
| SmartCard slot | No |
| Modem (RJ-11) ports | 0 |
| TV-in port | No |
| TV-out | No |
| PS/2 ports quantity | 0 |
| Parallel ports quantity | 0 |
| Serial ports quantity | 0 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | AMD RX781 |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad + Scroll zone |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Vista Home Premium |
Battery
| Specification | Value |
|---|---|
| Number of battery cells | 6 |
| Battery life (max) | 3 h |
Power
| Specification | Value |
|---|---|
| DC-in jack | Yes |
Security
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Password protection type | BIOS |
| HDD user password | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.68 kg |
| Width | 358 mm |
| Depth | 265 mm |
| Height (front) | 3.18 cm |
| Height (rear) | 3.85 cm |
| Dimensions (WxDxH) | 358 x 265 x 31.8 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
Other features
| Specification | Value |
|---|---|
| Infrared data port | No |
| Internal modem | No |
| Supplied AC adapter type | AC |
