Samsung N510-KA04FR Intel Pentium Mobile N270 Netbook

29.5 cm (11.6") 1 GB DDR2-SDRAM Windows XP Home Edition White

Model N510-KA04FRPart no. NP-N510-KA04FREAN 8808993589968

114 specifications Checked 3 days ago

Display29.5 cm (11.6")
Resolution1366 x 768 pixels
ProcessorIntel Pentium Mobile
Memory1 GB
Storage160 GB
Battery5200 mAh

See all specifications

Overview

Display: 29.5 cm (11.6")
Resolution: 1366 x 768 pixels
Processor: Intel Pentium Mobile
Memory: 1 GB
Storage: 160 GB
Battery: 5200 mAh

Brand: Samsung
Category: Laptop
Model: N510-KA04FR
Part number: NP-N510-KA04FR
EAN / UPC: 8808993589968
Also known as: Samsung N510-KA04FR Intel Pentium Mobile N270 Netbook 29.5 cm (11.6") 1 GB DDR2-SDRAM Windows XP Home Edition White

Specifications

114 specifications in 18 groups

Design

Specification	Value
Product type	Netbook
Product colour	White

Display

Specification	Value
Display diagonal	29.5 cm (11.6")
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium Mobile
Processor model	N270
Processor cores	1
Processor threads	2
Processor frequency	1.6 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor front side bus	533 MHz
Processor socket	Socket F (1207)
Processor lithography	45 nm
Processor operating modes	32-bit
Processor series	Intel Atom N200 Series
Processor codename	Diamondville
Bus type	FSB
FSB Parity	No
Stepping	C0
Thermal Design Power (TDP)	2.5 W
Tjunction	90 °C
Number of Processing Die Transistors	47 M
Processing Die size	26 mm²
CPU multiplier (bus/core ratio)	12
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Memory clock speed	800 MHz
Memory layout (slots x size)	1 x 1 GB
Memory slots	1x SO-DIMM

Storage

Specification	Value
HDD capacity	160 GB
HDD interface	SATA II
HDD speed	5400 RPM
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC

Graphics

Specification	Value
Maximum graphics card memory	0.128 GB

Audio

Specification	Value
Audio system	HD
Number of built-in speakers	2
Speaker power	3 W
Built-in microphone	Yes

Camera

Specification	Value
Front camera resolution (numeric)	1.3 MP

Network

Specification	Value
Wi-Fi	Yes
Networking features	Fast Ethernet
Wireless technology	IEEE 802.11b/g/n
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth version	2.1+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Microphone in	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard number of keys	83

Software

Specification	Value
Operating system installed	Windows XP Home Edition
Drivers included	Yes
Trial software	McAfee Virus Scan Microsoft Office
Bundled software	SAMSUNG Recovery Solution III Adobe Acrobat Reader

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	No
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	36331
Processor code	SLB73
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Battery

Specification	Value
Number of battery cells	6
Battery capacity	5200 mAh
Battery life (max)	7 h

Power

Specification	Value
AC adapter power	40 W
AC adapter input voltage	100 - 240 V
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
BIOS password	Yes
HDD user password	Yes

Weight & dimensions

Specification	Value
Weight	1.41 kg
Width	289 mm
Depth	199.5 mm
Height	26.5 mm
Height (front)	2.65 cm
Height (rear)	3.03 cm
Dimensions (WxDxH)	289 x 199.5 x 26.5 mm

Other features

Specification	Value
Supplied AC adapter type	AC
