13.3"

Model Versa S940 1.8GHz/512MB/60GB/DVD-RW/13.3"Part no. NN901701605

114 specifications Checked 6 days ago

Display33.8 cm (13.3")
Resolution1280 x 768 pixels
ProcessorIntel Pentium Mobile
Memory0.5 GB
Storage60 GB
GraphicsIntel® 855GM

See all specifications

Overview

Display: 33.8 cm (13.3")
Resolution: 1280 x 768 pixels
Processor: Intel Pentium Mobile
Memory: 0.5 GB
Storage: 60 GB
Graphics: Intel® 855GM

Brand: NEC
Category: Laptop
Model: Versa S940 1.8GHz/512MB/60GB/DVD-RW/13.3"
Part number: NN901701605
Also known as: NEC Versa S940 1.8GHz/512MB/60GB/DVD-RW/13.3" Intel Pentium Mobile 745 33.8 cm (13.3") 0.5 GB DDR-SDRAM Intel® 855GM

Specifications

114 specifications in 18 groups

Display

Specification	Value
Display diagonal	33.8 cm (13.3")
Display resolution	1280 x 768 pixels
HD type	Not supported
Native aspect ratio	5:3

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium Mobile
Processor model	745
Processor cores	1
Processor threads	1
Processor frequency	1.8 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	400 MHz
Processor socket	Socket 479
Processor lithography	90 nm
Processor operating modes	32-bit
Processor series	Intel Pentium M 700 Series
Processor codename	Dothan
Bus type	FSB
FSB Parity	No
Thermal Design Power (TDP)	21 W
Tjunction	100 °C
Number of Processing Die Transistors	144 M
Processing Die size	87 mm²
CPU multiplier (bus/core ratio)	18
ECC supported by processor	No

Memory

Specification	Value
Internal memory	0.5 GB
Internal memory type	DDR-SDRAM
Memory slots	2x SO-DIMM
Maximum internal memory	2 GB

Storage

Specification	Value
Total storage capacity	60 GB
HDD interface	Ultra-ATA/100
HDD speed	5400 RPM
Compatible memory cards	SD

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	Intel® 855GM

Audio

Specification	Value
Audio system	Built-in
Number of built-in speakers	2

Network

Specification	Value
Networking features	Wireless LAN, Fast Ethernet
Wireless compliance	IEEE 802.11b, IEEE 802.11g

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
CardBus PCMCIA slots quantity	1
CardBus PCMCIA slot type	Type II
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	Yes
TV-out type	S-Video
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
USB 1.1 ports quantity	0

Performance

Specification	Value
Motherboard chipset	Intel® 855GM

Keyboard

Specification	Value
Keyboard number of keys	87
Keyboard type	Standard layout

Software

Specification	Value
Bundled software	PowerDVD 5.0 RecordNow DX 7.2 Norton Antivirus 2004 (90 days) Microsoft Works 7.0
Compatible operating systems	Microsoft Windows XP Professional NL

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	No
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	27591
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Battery

Specification	Value
Battery capacity	4400 mAh
Battery life (max)	4 h

Power

Specification	Value
AC adapter power	65 W
DC-in jack	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C

Certificates

Specification	Value
Certification	CE Mark & CB

Weight & dimensions

Specification	Value
Weight	2 kg
Dimensions (WxDxH)	320 x 226 x 32 mm

Other features

Specification	Value
Security features	Kensington lock 2 levels passwords Recovery partition HDD
Infrared data port	Yes
Battery type	6-cell
Special features	Bluetooth
Wake-on-LAN ready	No
Wake-on-Ring ready	No
Internal modem	Yes
Modem speed	56 Kbit/s
Modem type	Data/Fax
Drive bays	2.5"
